SJN2 Vacuum Evaporator
Application:
This evaporator is suitable for concentrating the liquid in traditional Chinese medicine, Western medicine, glucose, starch, mono sidum glutamate, juice, water, dairy product, chemical industry, etc.
Especially, it is suitable for the low temperature vacuum concentration of heat sensitive materials.
Structure Drawing:
Structure:
Double-effect concentrator is composed of two tubular heaters, two evaporation chambers, circulating tube, condenser, liquid recycle tank, valves, meters, control box and other accessories.
Principle:
First fill the liquid into evaporator 1, then to heat the heater 1, the solvent from the evaporator 1 will be evaporated which will heat the heater 2 , then the solvent from evaporator 2 will be evaporated, it will glow to condenser, and it will be cooled by condenser and flow back to recycle tank.
Parameter:
Model | SJN2-500 | SJN2-1000 | SJN2-1500 | SJN2-2000 | SJN2-3000 |
Evaporate kg/h | 500 | 1000 | 1500 | 2000 | 3000 |
Cost air kg/h | 380 | 750 | 1100 | 1600 | 2500 |
Steam pressure Mpa | 0.1Mpa | ||||
Temperature | Number one 80-90 number two55-70 | ||||
Vacuum degree Mpa | Number one0.02-0.04 number two0.05-0.08 | ||||
Dimension L*W*H | 4.5*1*3.2 | 5.5*1.1*3.8 | 6.3*1.2*4.3 | 6.6*1.3*4.5 | 7*1.4*5.1 |
Circulate water T/H | 10-15 | 20-30 | 30-40 | 40-50 | 50-60 |
Feature:
1.Energysaving. Calculated based on type SJN-1000, it can save about 3500tons steam one year, 9 tons cooling water, 80000 kilowatt-hour, which is equivalent to about 20000 dollars. (compared with single-effect)
2.This concentrator adopts external heating natural circulation type and vacuum negative pressure evaporation type, which features rapid evaporation speed, high concentration ratio (about 1.2-1.35) (normally Chinese medical extract).
3.This concentrator adopts double effect evaporation simultaneously; second steam can be used well, which can save the steam boiler cost and energy consumption. Compared with single-effect concentrator, the energy consumption can be reduced by 50%. So, the energy-saving cost can recoup all the machine cost for you.
4.Multi-function operation: (1) it can be used to recovery the alcohol with 80% content; (2) Single-effect, double-effect can work together to collect the extract. (3) The feeding can be batch or continuous.
5.With the special structure, all the concentrated extract is of strong flavor and uniform paste. The liquid is concentrated under the sealing and foamless state without any leakage and less of pollution. Moreover, the material is not easy of coking; it is easy of cleaning and operation.
6.All the parts contacting with materials are made of SUS304 stainless steel. There are heat insulation layers covering the outer of heater and evaporator to protect operators.
How much liter of solvent do you want to be evaporated per hour?
What way do you heat the machine? By electric or steam?
What is the original degree of the solvent?
What is the finished degree of the solvent do you want to get?
What is your raw material?
When do you need this machine?
User demands analysis
Engineering design
Product manufacturing
Automatic control integration
Certification service
Engineers are available to go abroad to help installation
All the products before delivery should be tested by assemble&debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package. In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory.
All the products will be packed in wooden case. The exported products use plywood case to pack. The foot margin of equipment fixed tightly to make the machine can experience loading&uploading, the upward mark will be posted on the wooden case.
Our company is professional to manufacture and export pharmaceutical machine, food machine. Machines include:
Pharmaceutical machine:
Tablet press machine, blister packing machine, capsule filling machine, capsule / tablet counting production line, soft capsule making machine, mixing machine.
Liquid filling machine:
Vial filling machine, ampoule filing machine, wrapping machine, tube filling and sealing machine.
Food machine:
Jam, butter, chocolate packing machine, food tablet press machine and so on.
Export:
Machines have exported to South America, Europe, South-east Asia, and so on.
Welcome to contact with us.
