Home > Products > Emulsification Equipment > Automatic Electric Industrial Vacuum Mixing Homogenizer
Automatic Electric Industrial Vacuum Mixing Homogenizer
- 10 Set / Sets per Month
- Shanghai/Ningbo
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Mixer Type: | Agitator | Product Type: | Cosmetic |
Application: | Liquid | Additional Capabilities: | Other | Place of Origin: | Zhejiang, China |
Brand Name: | Sunny | Model Number: | TZZRJ-150 | Max. Loading Capacity: | depends on the volume |
Voltage: | 380V | Power(W): | 4kw | Dimension(L*W*H): | depends on the volume |
Certification: | CE ISO | Warranty: | 1 Year | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Vacuum Mixing Emulsifier
Application:
The equipment is suitable for emulsification of the pharmaceutical. Cosmetic, fine chemical products, especially the material having high matrix viscosity and solid content, such as cosmetic, cream, ointment, detergent, salad, sauce,lotion, shampoo, toothpaste and so on.
Structure Drawing:
Structure:
This homogenizer include main pot, water and oil pot, vacuum system, lift system, temperature system, control system and so on.
Principle:
First: put the raw material which can dissolved into water into water pot, then heat it, and mix it.
Second: put the raw material which can be dissolved into oil to oil pot, heat it and mix it.
Third: suck both of the raw materials into main pot, to homogenize the two materials by homogenizer.
Character:
Control by computer touch-screen, integrated operation, with beautiful generous;
Work continuously large quantity, circulating homogeneous discharging, especially suitable for single products continuous production.
Easy operation, perfect homogeneous emulsification
Capacity: 100-2000L
Helical ribbon mixing, internal external circulating homogenization.
Parameter:
Model | Volume | Emulsify | mixer | Outside dimension | |||||
Kw | r/min | Kw | r/min | L | W | H | M H | ||
TZZRJ-30 | 30L | 1.5 | 0-3500 | 0.75 | 0-70 | 1500 | 800 | 1500 | 2050 |
TZZRJ-50 | 50L | 3 | 0-3500 | 0.75 | 0-70 | 2750 | 2100 | 1900 | 2600 |
TZZRJ-100 | 100L | 3 | 0-3500 | 1.5 | 0-70 | 2800 | 2150 | 2100 | 2800 |
TZZRJ-150 | 150L | 4 | 0-3500 | 1.5 | 0-70 | 2850 | 2150 | 2150 | 2900 |
TZZRJ-200 | 200L | 4 | 0-3500 | 1.5 | 0-70 | 3000 | 2200 | 2200 | 3100 |
TZZRJ-350 | 350L | 5.5 | 0-3500 | 2.2 | 0-70 | 3650 | 2650 | 2550 | 3600 |
TZZRJ-500 | 500L | 7.5 | 0-3500 | 2.2 | 0-50 | 3800 | 2800 | 2700 | 3950 |
TZZRJ-750 | 750L | 11 | 0-3500 | 3.7 | 0-50 | 3900 | 3900 | 2900 | 4400 |
TZZRJ-1000 | 1000L | 11 | 0-3500 | 3.7 | 0-50 | 3900 | 3400 | 3150 | 4550 |
TZZRJ-2000 | 2000L | 22 | 0-3500 | 7.5 | 0-50 | 4850 | 4300 | 3600 |
|
How much capacity do you need?
What way do you heat the machine by steam or electric ?
Do you need automatic one or manual one?
Do you need water and oil pot or not?
What is your raw material?
What is the voltage? Is it 380V 50hz 3phase?
When do you need ?
User demands analysis
Engineering design
Product manufacturing
Automatic control integration
Certification service
Engineers are available to go abroad to help installation
All the products before delivery should be tested by assemble & debugging engineer, wiped up and cleaned, then wrapped by stretch film to protect it from moist. The precision part need to flexible package. In addition, without standard tools, manual and other documents, and allow ex-factory confirmation sheet, the machine cannot leave factory.
All the products will be packed in wooden case. The exported products use plywood case to pack.
The foot margin of equipment fixed tightly to make the machine can experience loading & uploading, the upward mark will be posted on the wooden case.
Our company is professional to manufacture and export pharmaceutical machine, food machine. Machines include:
Pharmaceutical machine:
Tablet press machine, blister packing machine, capsule filling machine, capsule / tablet counting production line, soft capsule making machine, mixing machine.
Liquid filling machine:
Vial filling machine, ampoule filing machine, wrapping machine, tube filling and sealing machine.
Food machine:
Jam, butter, chocolate packing machine, food tablet press machine and so on.
Export:
Machines have exported to South America, Europe, South-east Asia, and so on.
Welcome to contact with us.
