Mono Coil Tube (Fiber Optic Protection Tube)
The Mono Coil Tube (Fiber Optic Protection Tube / Spiral Protection Tube) is in micro diameter and light weight. Excellent flexibility offers the convenience and ease of deployment at corners and prevents the line from damage. After covering with SUS braiding, the tube is capable to resist press and improper twist. Reinforced tensile strength can be reached by using Kevlar. The material of outer coating can be made according to environment conditions and can be recognized by 12 colors.
Feature:
Series Number: TMC Series
Tube Material: Stainless Steel
Braiding Material: Stainless Steel
ID: ø1.0 ~ ø8.0mm
OD: ø1.5 ~ ø8.8mm
OD with Braiding: ø1.9 ~ ø9.5mm
OD with Braiding & Coating: ø2.5 ~ ø11.0mm
Coating Material: PVC / HDPE / LDPE / LSZH
Coating Color: Black / Grey
Temperature Range: -20 °C ~ 70 °C
| Code | ID (ø mm) |
OD (ø mm) |
OD w/Braiding (ø mm) |
OD w/Braiding & Coating(ø mm) |
Min. Bending Radius(mm) | Packing Length(m) |
| TMC-001 | 1.0 | 1.5 | 1.9 | 2.5 | Dynamic = 20 x D Static = 10 x D (D= Optic Dia.) |
1000 |
| TMC-002 | 1.1 | 1.6 | 2.0 | 3.0 | 1000 | |
| TMC-003 | 1.5 | 2.1 | 2.6 | 3.3 | 1000 | |
| TMC-004 | 2.2 | 2.8 | 3.4 | 5.0 | 1000 | |
| TMC-005 | 3.0 | 3.8 | 4.5 | 6.0 | 1000 | |
| TMC-006 | 4.0 | 4.8 | 5.5 | 7.0 | 1000 | |
| TMC-007 | 4.6 | 5.5 | 6.2 | 7.5 | 1000 | |
| TMC-008 | 5.0 | 5.8 | 6.5 | 8.0 | 1000 | |
| TMC-009 | 6.0 | 6.8 | 7.5 | 9.0 | 1000 | |
| TMC-010 | 7.0 | 7.8 | 8.5 | 10.0 | 1000 | |
| TMC-011 | 8.0 | 8.8 | 9.5 | 11.0 | 1000 |
Application:
Mainly for fiber optic protection, such as sensing system and communications equipment, besides, endoscopy or laparoscopy as well.
Kaiphone Technology Co., Ltd. has been specializing in producing Flexible Metal Conduit and Flexible Metal Conduit Fitting for over 30 years in Taiwan, superior quality is guaranteed. In addition to Flexible Metal Conduit, we also supply associated OEM products, such as Armored Fiber Optic Cable, Kitchen/Shower Accessories, Payphone Accessories and various kinds of tube assembly products with durable quality and reasonable price. Our main products include UL Listed Conduit, Liquid Tight Flexible Conduit, Flexible Gooseneck Tube, Corrugated Tube, UL Listed Conduit Fitting, Armored Fiber Optic Cable, Shower Hose, Flexible Spout Tube and so on. If you are searching for high quality Flexible Metal Conduit and Wire/Cable Harness Assembly Manufacturer, Kaiphone will be your best choice. Please feel free to contact us.
