Specifications
1.For optical cable,telephone cables, telecommunication cable2.For cable shielding
1.Application:
1.Used for optical cable
2.Used as waterproof materials
3.For telephone cables
4.For cable shielding Aluminum polyethylene tape
2.Pecifications:
Thickness, length and width can according to customer requorements
Name |
Aluminum double coated |
Thickness |
150µ-600µ |
Width |
17mm-540mm |
ID(inner diameter) |
53.5mm / 76mm / 102mm / 150mm (2.1in / 3.0in / 4.0in / 5.9in) |
ID material |
Plastic or Metal |
OD(outer diameter) |
500-900mm |
Color |
Silver/Green/Blue |
Packaging |
Carton,Then put on a plywood pallet |
S.NO. |
Item |
Unit |
Requirement |
|
1 |
Appearance |
|
The surface is plain, smooth, uniform. |
|
2 |
Tensile Strength |
Mpa |
≥50 |
|
3 |
Break Elongation |
% |
≥15 |
|
4 |
Bond Strength between steel tape and plastic film |
N/cm |
≥6.13 |
|
5 |
Cutting Strength of Heal Seal of Plastic Clad Steel tape |
|
Damage between coating and steel tape, no cutting damage between heat seal area of coating |
|
6 |
Heat Seal Strength of Plastic Clad Steel Tape |
N/cm |
≥17.5 |
|
7 |
Water Tolerance(68±1°C,168h)Bond Strength |
N/cm |
≥6.13 |
|
8 |
Jelly Resistance(68±1°C,168h) |
|
No separation between steel tape and pastic film |
|
9 |
Corrison Resistance(0.1mol/L HCI,480h) |
Grade |
≥7 |
|
10 |
Dielectric Strength |
One-sided Plastic Clad Steel Tape 1kV, DC, l min. |
|
Without Breakdown |
|
Two –seded Plastic Clad Steel Tape 2kV, DC, 1 min |
|
Without Breakdown |
||
3.Test report andtese machine
| No. | Name |
Width (mm) |
Thickness (mm) |
Tension (N) |
Tensile atrength (MPa) |
Elongation at break (%) |
| 1 | Aluminum double coated | 28.000 | 0.25 | 490.09 | 68.910 | 23.500 |
| 2 | Aluminum double coated | 28.000 | 0.25 | 487.95 | 68.610 | 22.250 |
4.Production line: Paster & Cutting
5.Product pictures:
Green color
Silver color
Blue color
6.Packaging photos:
a.Carton,Then put on a plywood pallet
b. Inner-plastic bag,Outside-carton,Then put on a plywood pallet
7.Warehouse
8.Application to Cables
9.Certificate:We have ISO,Supply SGS,Certificate of original,MSDS,Test report,ect
10.Sample: We are manufacturer,We supply free sample,But please pay express fee.
11.Contact:Please feel free to contact with me.
Mobile:86-15168349992
FAX:86-571-6381 0799
