Specifications
1.For wire cables2.For insulation materials
3.Supply RoHS,Certificate of original,MSDS,Test report,ect
1. Application
1.For wire cables
2.For insulation materials
3.For telephone lines
4.For flexible duct,air conditioner
5.For packaging
6.Supply RoHS,Certificate of original,MSDS,Test report,ect
7.We are manufacturer
2. Specifications
Name |
Blue color Insulation film corona aluminum foil mylar coxial cable |
Thickness |
20u-150u |
Width |
5mm-1000mm |
Inner diameter |
53.5mm(2.1in) or 76mm(3.0in) |
Outer diameter |
250mm-650mm |
Color |
Silver,Blue,Golden,Green,Pink,Yellow |
Packaging |
1.Inner-plastic bag,Outside-carton,Then put on a plywood pallet 2.Inner-plastic bag,Outside plywood wooden box |
Certificate |
RoHS,ISO9001 |
Tensile Strength |
≥50 Mpa |
Elongation at break |
≥35% |
Name:AL+PET |
|
|
|
Structure |
Thickness(mic) |
Weight(g/m2) |
Yield(m2/kg) |
AL7+ PET12 |
21mic |
36 |
|
AL7+ PET15 |
24 mic |
39 |
|
AL9+ PET12 |
23mic |
43 |
23 |
AL9 +PET15 |
26mic |
48 |
21 |
AL9 +PET19 |
30mic |
54 |
19 |
AL9 +PET23 |
34mic |
60 |
17 |
AL12 +PET12 |
26mic |
52 |
19 |
AL12 +PET15 |
29mic |
56 |
18 |
AL12 +PET23 |
37mic |
67 |
15 |
AL12 +PET36 |
50mic |
87 |
12 |
AL15 +PET23 |
40mic |
74 |
|
AL25 +PET12 |
39mic |
87 |
12 |
AL25 +PET23 |
50mic |
102 |
10 |
AL40 +PET15 |
57mic |
131 |
8 |
AL40 +PET23 |
65mic |
143 |
7 |
AL50 +PET12 |
64mic |
154 |
6 |
3.Test report and test machine
| Width (mm) |
Thickness (mm) |
Tension (N) |
Tensile atrength (MPa) |
Elongation at break (%) |
| 17.000 | 0.030 | 76.39 | 150.678 | 106.031 |
4.Production line: Lamination & Cutting
5.Product pictures
6.Packaging photos
a.Inner-plastic bag,Outside-carton,Then put on a plywood pallet
b.Inner-plastic bag,Outside plywood wooden box
7.Warehouse
8.Application to Cables and Flexible Ducts
9.Certificate:We have ISO,Supply SGS,Certificate of original,MSDS,Test report,ect
10.Sample: We are manufacturer,We supply free sample,But please pay express fee
11.Contact:Please feel free to contact with me
Mobile:86-15168349992
FAX:86-571-6381 0799
