New 1.5U Casing 36CH 960P/720P& 25Ch 2MP NVR For 5MP/3MP/1080P IP Camera Network Video Recorder With Onvif P2P View 4 Sata HDD
• P2P cloud service, including cloud connecting, cloud monitoring, cloud transmitting to access IPC and NVR at any time and any place with:
• Support Onvif protocol, support High profile S, High profile G, compatible with different IP camera that based on Onvif, RTSP standard
• Support megapixel HD network video preview, storage and playback;
• Support search, playback and backup by event;
• Support all channel image display on one screen at same time, support 4 channels’ image display by mainstream,and 4 channels playback;
• Support monitor PTZ on preview mode
• Offer CMS for free
• support 4 SATA(4*4TB=16TB)+1 E-SATA HDD ports
Main Functions:
1. Preview channel can be switched to other channel randomly without changing the MAC which is convenient for the project construction;
2. The dendritic menu can be moved. Man-machine communication is more direct and the settings of parameters are more easy and convenient;
3. The mouse roller can realize 15x digital zooming which the enlarged image can be dragged and moved randomly under preview and playback modes;
4. Immediate snapshot and immediate view; the picture will be stored in an independent area in the HDD;
5. The recording playback is shown by time bar and different color represents different recording type. It is very fast and easy to find check the recording;
6. Recording backup can be accurate to second. Any time period of backup is available;
7. The recording files in the USB disk can play directly in the playback interface while the snapshot pictures can be viewed directly;
8. With 3G, WIFI wireless connection functions;
9. Standard resolution which can be adjusted according to the display device in order to get the best image quality;
10. Adopt HDD sequence writing method and the data is written from 0 track which increase 2.5X lifetime of the HDD
Note:Single channel 1080P supports max. 8M code stream, single 720P suports max. 4M code stream, total 150M(i8s)
Model Number |
N6000-36EF |
|
Operating System |
Embedded LINUX operating system |
|
Image Code Control |
Image code quality adjustable, variable bitstream and constant bitstream optional |
|
Dual Stream |
Each channel can set main stream and sub stream |
|
Video Standard |
5.0P(2592*1944)30fps/3.0P(2048*1536)30fps/2.0P(1920*1080)30fps/1.3P(1280*960)30fps |
|
Monitoring Image Quality |
5.0P(2592*1944)/3.0P(2048*1536)/2.0P(1920*1080)/1.3P(1280*960) |
|
Image Motion Detection |
Each screen can set mutiple detection areas and set 6-level sensitivity(IPC Support) |
|
Recording Playback Quality |
Any 9ch 720p/960p playback ;4ch 1080P /3mp/;1ch 5mp playback |
|
Region Cover |
Every channel can set 4 cover regions(IPC Support) |
|
Recording Mode |
Support manual , auto, dynamic detection, alarm trigger record mode(Partly needs IPC Support) |
|
Backup Way |
Support U disk, USB mobile HDD, USB DVD-RW, network storage and backup |
|
Operation Way |
Mouse |
|
Local Login |
User name and password |
|
Recording Storage |
Local HDD, network |
|
External Ports |
Video Input |
1.36×(1280*960)+sub[960*576]+4Ref.+9Play 36ch 1.3MP IP Camera |
2.25x(1920*1080)+sub[960*576]+4Ref.+4Play 25ch 2.0MP IP Camera | ||
3.16×(2048*1536)+sub[960*576]+4Ref.+4Play 16ch 3.0MP IP Camera | ||
4.4x(2592*1920)+sub[960*576]+4Ref.+4Play 4ch 5.0MP IP Camera | ||
Audio Input |
25ch network audio input, 1ch RCA output |
|
Video Output |
1ch VGA+1ch HDMI |
|
Network Port |
1 RJ45,10M/100M/1000M self-adaptive LAN port |
|
Alarm Input |
4ch |
|
Alarm Output |
1ch |
|
USB Port |
1 USB 3.0 port, 2 USB 2.0 ports |
|
Wireless Port |
3G,WIFI |
|
HDD |
HDD Port |
4 SATA HDD Port |
MAX Capacity |
Each port supports MAX 4TB HDD |
|
Mobile Surveillance |
Support( iPhone, Windows Mobile, BlackBerry, Symbian, Android) smart phone |
|
Power Supply |
ATX110-220V 300W 50-60Hz |
|
Power Consumption |
≤25(without HDD) |
|
Working Temperature |
-10~+55 |
|
Working Humidity |
10%-90% |
|
Weight(without HDD) |
N.W.:5.7Kg;With packing:6.9Kg |
|
Dimension |
Equipment:440mm×360mm×70mm, Packing: 460mm×135mm×560mm |
|
Installation Way |
Desktop Installation |
|
1 x 36CH 720P/960P /25CH 1080P NVR
1 x DC 12V Power Adapter
1 x Screws Set
1 x USB Mouse
1 x HDMI Cable
1 x CD with Mobile Software and NetViewer
1 x User Manua
OEM Service:
We could offer OEM and ODM services for our clients.
Delivery Time:
Sample order 3-5 working days, bulk order 7-15 working days.
Quality Warranty:
2 years for free repair. Whole life service for continue cooperating customers!
Price Term:
FOB Shenzhen
Delivery Term:
By Express(DHL/FEDEX/TNT/UPS/EMS/CHINA POST),By air,By Sea.
