Swimming pool side mount sand Filter

Specifications

Swimming pool side mount sand Filter
1).Side mounted
2).6 ways valve
2).Fiberglass bobbin wound
3).PC transparent top cover

Swimming pool side mount sand Filter



Product Name: Hydroswim side mount sand filter



Aplications: Swimming pool



Advantages:



Designed and engineered by the latest European technology,manufactured with laminated fiberglass,molded of durable, UV resistant,corrosion-proof and Gel Coat smooth finished.

PVC grey top cover and PC transparent top cover for options.Transparent cover allows easy inspection of the sand bed.Top diffusers ensure every distribution of water over the top of the sand bed.



Features Hightlight

• Qualified and Certifyed test by NSF50 standards
• High strength due to adopt glass fiber inner of the tank
• High efficient back wash

Specifications





Model No.	TANK Dia. B(mm)	Height A(mm)	Height C (mm)	Valve Port Size (mm)	Filter Area (m2)	Silica Sand (kg)	Design Flow (m3/h)	Gross Weight (kg)	Package Sizes (cm)	Package Type (material)
450	450	670	590	40	0.16	40	7.98	16.5	49*49*83	Master carton
550	550	710	630		0.22	85	11.52	21.1	57*57*71
650	650	830	660		0.30	155	16.20	24.3	68*68*83
700	700	895	690		0.40	185	19.20	33.0	73*73*86
800	800	1030	900	50	0.50	210	25.20	41.5	84*84*96
900	900	1130	930		0.64	310	30.00	52.3	94*94*108
1000	1000	1230	930		0.79	410	33.00	95.0	107*107*125	Wooden crate
1100	1100	1310	990		0.98	460	37.80	115.0	117*117*135
1200	1200	1430	1020		1.13	560	42.00	124.0	127*127*144	Wooden pallet
1400	1400	1680	1100		1.54	900	57.00	182.5	145*145*160
