Help CenterPromotion Led Panel 600x600
US$ 49.56 - 62.89
MOQ: 50 Pieces
Key Specifications
Get Latest Price
LED Light Source:
Epistar chips
Warranty(Years):
2
Input Voltage(V):
85-270V AC
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Promotion 600x600 Led PanellightUS$ 49.56 - 62.89MOQ: 50 Pieces -
High Brightness 36W Led Panel 600x600 AC100~240V Led Panel 60x60US$ 79.6 - 95.52MOQ: 100 Pieces
-
SMD Led Panels Lights 600*600, Led Panel Lights,modern Ceiling LightsUS$ 78.6 - 95.52MOQ: 100 Pieces
-
48w 300x1200m Flat Panel Ceiling LightUS$ 97.32 - 116.04MOQ: 100 Pieces
-
48w 300x1200m Led Flat Panel Modern Wall LightUS$ 97.32 - 116.04MOQ: 100 Pieces
LED Light Source
Epistar chips
Warranty(Years)
2
Input Voltage(V)
85-270V AC
Lamp Power(W)
36
Lamp Luminous Flux(lm)
2520
Lamp Luminous Efficiency(lm/w)
70
Color Temperature(CCT)
Cool White
Working Temperature(℃)
-20, 55
Working Lifetime(Hour)
50000
Lamp Body Material
Other, Aluminium frame with milky PMMA cover
IP Rating
IP33
Place of Origin
Guangdong, China
Brand Name
OEM Optosun
Model Number
led panel light OS-PL6060-36, led panel light OS-PL6060-36
Specifications
lamps for home1.smd3014 leds adopted;
2.Factory direct sale
3.2 years warranty
4.UL driver
promotion led panel 600x600
Specifications:
led panel light:
Can be ceiling or wall surface-mounted
Main material : Aluminum+PMMA+PS
Ultra-slim and low-profile
| Model No. | OS-PL6060-36 |
| LED light sources: | SMD3014 |
| LED panel light dimension: | 600x600x12mm |
| LED quantity: | 360pcs SMD LEDs |
| Power consumption: | 36w |
| Luminous efficiency: | 70lm/W |
| Color of LED panel: | cool white color(or warm white ) |
| LED driver feature: | UL listed |
| Input voltage: | 85-270V AC |
| CCT: | 5000-6500k |
| Gross weight: | 4.8kg |
| warranty: | 5 years |
| Beam angle: | 120° |
| Lifespan: | ≥50,000 hours |
| Material : | Aliminum frame with PMMA cover |
Advantages:
1.Using high power self-produce 3014SMDs with competitive price.
2.Using high power 3014smd with suoerior quality;
3.70%-80% savings on lighting cost
4.Super bright 36Watt,compare with 60Watt traditional light
5.Good heat dissipation.
6.50,000hrs long lifespan.
7.5 Years Warranty
8.IP33 for indoors lighting.
| Item NO. |
Wattage (W) |
Spec. |
Voltage (V) |
Color |
Lumino us Flux (LM) |
Beam Angle |
Color temperature (K) |
LED Quantity (pcs) |
Power Supply Type |
|
OSPL6060- 54 |
54 |
600*600* 12mm, Aluminium frame with milky PMMA cover |
AC110-270V | Pure white/Warm white | 2700-8000 | 120° | 3300-4000 | 528 |
external constant current driver |
|
OSPL6060- 48 |
48 |
600*600* 12mm, Aluminium frame with milky PMMA cover |
AC110-270V | Pure white/Warm white | 2700-8000 | 120° |
2900- 3300 |
484 |
external constant current driver |
|
OSPL6060- 36 |
36 |
600*600* 12mm, Aluminium frame with milky PMMA cover |
AC110-270V | Pure white/Warm white | 2700-8000 | 120° |
2200- 2770 |
360 |
external constant current driver |
|
OSPL6060- 27 |
27 |
600*600* 12mm, Aluminium frame with milky PMMA cover |
AC110-270V | Pure white/Warm white | 2700-8000 | 120° |
1900- 2100 |
264 |
external constant current driver |
Installation:
Package:
Applications:
Related products:
About us:
