1/3"SONY CCD,700TVL, High Speed Dome Camera

Name: 1/3"SONY CCD,700TVL, High Speed Dome Camera
Brand: sinovision
SKU: 123474791
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

sinovision

Model Number:

MPT-001-10

Sinovision Technology (Shenzhen) Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

SHENZHEN

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name sinovision

Model Number MPT-001-10

Type Digital Camera

Style Dome Camera

Sensor CCD

Technology Infrared

Special Features Waterproof / Weatherproof

Specifications

1/3"SONY CCD,700TVL, High speed dome camera
*10 plus Zoom lens,color B and W auto switch
*Waterproof grade:IP66
*360 ratating

1/3"SONY CCD,700TVL, High speed dome camera

Feature

1.Intelligent outdoor speed dome camera with

Multi protocol, OSD, Path memory, Privacy

2.masking and day & night function.

3.360° continuouse pan rotation

4.90° vertical auto-flip to follow object

5.Privacy Zone Masking Function

6.Self-study

7.128 preset positions

8.OSD function

9.Camera rotating angle display

10.RS-485 communication,Multi-protocol

Specification

MODEL	PT-001
Address	0~255
Pan range	360° continuous pan rotation
Tilt range	0 °— 100 °
Pan speed	0.5 °— 300 ° / sec
Tilt speed	0.5 °— 150 ° / sec
Preset callback rate	H:250º/sec,V:150º/sec
Preset position number	128
Preset accuracy	±0.10°
Power Off memory	Powering on self-restoring style
Supporting camera	Automatically detect 8 kinds of camera(Sony,Hitachi, CNB, LG, and Samsung)
Operating Temperature	–30 °C —50 °C
TV system	PAL/NTSC
Frequency	H:15.625KHz(15.734KHz) / V:50Hz(60Hz)
Synchronization	Internal/External(V-Lock)
S/H (Y signal)	> 50dB/>52dB(AGC off )
Electronic shutter	Auto,1/1 to 1/10,000 s-1/50~1/30,000sec
White Balance	Auto /Manual
Gain Control	Auto /Manual
Backlight Compensation	ON/OFF
Privacy Function	On/Off (8/24 positions)
Video Output	VBS: 1.0 Vp-p (sync negative), Y/C Output
Focus	Auto / Manual
Zoom Module Operation Temp.	0°C- 50°C
Protection level	IP66
Power supply	AC 24 V
Power Consumption	20 WZ(heater open up 45W )
Communication protocol	Pelco P/D
Baud Rate	1200/2400/4800/9600
Communication Interface	RS485 (+/-)
Wiring	Coaxial line
surge and lightning protector	Embed in
Installation Environment	Outdoor,
