11pcs ir led pt ip wiriless home security camera
- 100000 Piece / Pieces per Month
- Shenzhen or HK
- Credit Card
- 7 inch TFT Monitor DIGITAL Wireless Farm Cctv Systems
- 7 inch TFT Monitor DIGITAL Wireless New Backup Camera Kit with 2.4GHz digital signal
- 7 inch TFT Monitor Digital Reversing Camera System with 2.4GHz digital signal
- 7 inch TFT Monitor Wireless Back Up Systems with 2.4GHz digital signal
- Car Camera Wireless Transmitter System For Bus
- 7inch digital 2.4g wireless surveillance camera system For Bus
Product Details
Place of Origin: | Guangdong, China | Brand Name: | OEM | Model Number: | SN-IPCH10-MPT01 |
Type: | IP Camera | Style: | Other, robot | Sensor: | CMOS |
Technology: | NetWork | Special Features: | Other, smart home |
Product Description
11pcs ir led pt ip wiriless home security camera
Feature
*Captures 720p, High-Definition (HD) video and images
*Pan (Horizontal Control): 355° - Tilt (Vertical Control): 120° - with 15 Presets available
*11 LEDs along with advanced IR cut technology, captures clear images in the dark at up to 10 meters
*2-Way audio communication - built-in microphone and speaker with 3.5mm auxiliary audio input and output
*Supports (up to) 64GB Micro SD Card for recording (Micro SD Card sold separately)
*Remote access from iOS/Android Devices (smartphones, tablets, etc.), from a local computer, or from any computer via the cloud
*Simple Plug-n-Play installation - no complicated programming or port forwarding required
Specification
Camera | SN-IPCH10-MPT01 |
System security | Account, password authority management |
Free DDNS | Free DDNS, supports dynamic IP |
View by phone | Support HD pic IOS, Android mobile view (iOS 4.3,Android OS 2.3 above) |
Local Storage | support up to 64GB MicroSD card ,24-hour loop recording. |
Monitor Advantage | Support PC computer monitoring, smartphone multi-pic view. |
PnP | Plug & Play,99% penetration rate, Easy to setup: 1. connect the network cable and power adapter 2.install APP, scan UID code to add camera. 3,Click online camera to view the camera. |
Sever cluster | Using Amazon Cloud PnP servier cluster, intelligent application and super stable |
UID Technology | UID scan technology applied, easy to operate, and highly confidential. |
Super Client | 1,4,9,16,25,36, 64,81-channel central management software, no user number limitation, centralized surveillance, remote record and playback, alarm email ect. |
System | |
OS | Embedded Linux OS |
Control protocol | ONVIF 2.0 protocol, high interoperability |
Video coding | Multi stream:720P@30fps+VGA@30fps+QVGA@30fps+720P @1fsJPEG capture |
Bit Rate | CBR/VBR, output bit rate range:128~4096kbps |
Processor | Hi processor, built in ARM926 @Max. 440MHz and high-speed video co-processor |
Video | |
Compression Format | H.264 baseline profile@levels:3.1/Motion-JPEG |
Frame rate | 30fps/24fps(720p) |
Resolution | 720P(1280*720), VGA(640*480), QVGA(320*240) |
Picture Adjustment | Contrast, Brightness, Saturation are adjustable. |
Sensor | 1/4 720p Progressive CMOS sensor |
Minimum illumination | 0.8Lux/F1.4(colourful model ),0.3Lux/F1.(B&W mode) |
SNR | ≥39dB |
IR control | IR turned on: night vision view enabled, infrared Ray, ICR auto detect. IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode. |
Electronic shutter | 1/50s(1/60s)-1/100, 000s |
CMOS | support AWB, AGC, BLC |
Lens/viewing angle | 3.6mm @F1.4/56.14° |
Night vision | Dual IR-CUT Filter auto switch, 11pcs 850nmΦ5mm LED,10m IR distance |
Audio | |
Compression format | ADPCM/32kbps |
Input | 1 Channel Line in (3.5mm phone jack) &1 Channel Internal -48dB Microphone |
Output | 1 Channel Line out (3.5mm phone jack)&Internal speaker(8Ω1W) |
P/T | |
P/T | Pan:355°,Tilt:120° |
Preset Postion | suppor up to 15 preset postions |
Network | |
network interface | 10Base-T/100Base-TX Ethernet interface |
Network Protocol | TCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P,etc. |
wireless network security | WPS encryption |
Online visitor | Support 4 online visitors simutaneoursly |
IP address | Dynamic IP and static IP address |
WIFI | WIFI 802.11 b/g/n |
Others | |
housing material | engineering plastics |
Application environment | Indoor |
Rated Voltage | DC5±0.3V |
Temperature | -10~50 °C |
Power consumption | rated power:3.5W(IR opening )/maximum power:7W(P/T working ) |
Package size | 195x140x130mm (L×W×H) |
Weight | Gross Weight :755g(Note: in kind prevail) |
Accessories | Power adapter, user manual, warranty card, mounting bracket, screws. |
Alarm | |
Motion Detection | Support motion detecting |
System configuration | Win98 SE/ME/2000/XP,Vista,iPhone iOS4.3,The android version 2.3 or higher |
How can I get some samples?
We are honored to offer you samples.But free sample is not available to new scustomer,when you become our VIP,you will have this privilege.
What's your MOQ?
No MOQ for any sample,at least 50pcs/model after sample order.
Is OEM,ODM service available?
Yes,we providevariety OEM Services,like printing logo,Label,Packing box,when reach 50pcs/Mode. ODM will be based on the quantity.
Payment:
1.Price Terms:EXW,FOB SHENZHEN(Shipping cost are quoted under your requirement)
2.Payment terms:L/C,T/T(USD/RMB).Western union.Paypal etc.
Delivery Time:
Sample order,3-7days after payment cleared;Bulk order,7-14 days after payment cleared.(Working days upon receipt of deposit)
Warranty:
1.Warranty: 18 Month for DVR & NVR ;24 Months for Cameras;
2.The warranty starts from the delivery date from our factory;
3.During the warranty,any defective products can get repaired or replaced for free;
4.The warranty is unavailable for those products which are broken by the violence,the carelessness,
repaired or altered without the authorization.
5.Provide 7*24h services.
