2012 Good Quality Led Strip 5v Dmx Rgb Led Strip Light

2012 Good Quality Led Strip 5v Dmx Rgb Led Strip Light thumbnail-1
2012 Good Quality Led Strip 5v Dmx Rgb Led Strip Light photo-1
US$ 7.58 - 11.98 MOQ: 500 Meters
Key Specifications
Get Latest Price
LED Light Source:
5050SMD LEDs
Type:
Flex LED Strips
Input Voltage(V):
DC5V
Contact Supplier Request Quote Chat Now
Shenzhen Optosun LED Technology Company Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
LED Light Source 5050SMD LEDs
Type Flex LED Strips
Input Voltage(V) DC5V
Lamp Power 6.5-7.2W/M
Lamp Luminous Flux(lm) 540-600lm/m
Working Temperature(℃) -40, +55
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum
Certification CE
Emitting Color RGB
Place of Origin Guangdong, China
Brand Name OEM Optosun
Model Number dmx rgb led strip light OS-WS5-5050RGB-32

Specifications

dmx rgb led strip light
1.IP65 32leds IC ws2811
2.CE RoHS Approval
3.UL power supply
4.OEM ODM&DIY

dmx rgb led strip light

Specifications:

LED Color

RGB dream color

LED light source

SMD5050 LEDs

LED Qty

32leds/m
Luminous flux of each led

18-20lm

Color of PCB

Yellow/white/Black

Working Voltage

DC 5V

Power Consumption

6.5-7.2W/M
Luminous Flux

540-600lm

Beam angle

120 degree

Waterproof  Grade

IP68

Lighting Decay

less than 3% after 3000 hours

Working Tempreture

Working temperature:-40°C~+55°C

Life Span

50.000 hours

Warranty

2 years



CCT/Wavelength of DMX rgb led strip light:

White Warm white Pink Yellow Green Red Blue Purple
5500-6500K 3000-3500K 420-430nm 585-595nm 515-525nm 625-630nm 465-470nm 370-410nm
Voltage LED QTY Power Work current Luminous flux of each led LED type Color IC QTY
DC5V 30leds/m or 32leds/m 6.5-7.2W/M 540-600mA/M 18-20lm 5050SMD LEDs RGB dream color 30pcs or 32pcs
DC12V 30leds/m 6.5-7.2W/M 540-600mA/M 18-20lm 5050SMD LEDs RGB dream color 10pcs
DC24V 60leds/m 13-14.4W/M 1080-1200mA/M 18-20lm 5050SMD LEDs RGB dream color 10pcs



Package of DMX rgb led strip light:

2012 Good quality led strip 5v dmx rgb led strip light

Details of dmx rgb led strip light:

2012 Good quality led strip 5v dmx rgb led strip light

2012 Good quality led strip 5v dmx rgb led strip light

2012 Good quality led strip 5v dmx rgb led strip light

 2012 Good quality led strip 5v dmx rgb led strip light

Advantages of dmx rgb led strip light:

1.Using self-produced 5050SMDs ensuring realiable quality and competitive price;

Green: 515-525nm(Single LED Intensity:1800-2200mcd    12*13mil Chip Size)
Red: 620-625nm(Single LED Intensity:600-800mcd    10/11/12mil Chip Size)
Blue: 465-470nm(Single LED Intensity:300-500mcd    12*13mil Chip Size)
2.UL power supply is more stable than others.

3.Led strip 5050 is non yellowish and stay flexible even in temepature below zero degree C.

It's much clearer than traditional epoxy glue.

4.Various colors for your different choice.

5.Lifespan:>50,000hours
6.Low temperature resistance, Not easy to break.

7.Every 3LEDs cuttable.

8.DMX controller or Multi-color controller are available.

9. CE RoHS Approval.

10.IC ws2811 is upgrade of ws2801.



Applications of dmx rgb led strip light:

1.Outdoors decoration;

2.Large scale backlight;

3.Building contour decorative lighting;

4.Ad signs, light boxes; Profile lighting;

5.Window display lighting

6.For Christmas show/Halloween show/Party lighting.etc

2012 Good quality led strip 5v dmx rgb led strip light

2012 Good quality led strip 5v dmx rgb led strip light2012 Good quality led strip 5v dmx rgb led strip light









Relate products:

2012 Good quality led strip 5v dmx rgb led strip light

2012 Good quality led strip 5v dmx rgb led strip light

2012 Good quality led strip 5v dmx rgb led strip light

2012 Good quality led strip 5v dmx rgb led strip light



Aging of dmx rgb led strip light:

2012 Good quality led strip 5v dmx rgb led strip light



Our main products:

2012 Good quality led strip 5v dmx rgb led strip light



Our factory:

2012 Good quality led strip 5v dmx rgb led strip light



Our service:

1. Your inquiry would be replied in within 24 hours.

2. Your special requirements of dmx rgb led strip light can be accepted.

3. Reasonable price would be provided by your order qty.

4. 5 years experience of production will always provide you pretty competitive price and superior goods.

5. 10 years experience engineers would be provided you helpful free technical.

6. 1300-square-meter factory can output at least 50KK SMD LEDs and 70K LED lighting monthly, To effect delivery smoothly.

7. Reasonable shipping cost are quoted under your requests.
