Addressable Rgb Led Strip Ws2801 for Decoration

Addressable Rgb Led Strip Ws2801 for Decoration photo-1
US$ 5.98 - 8.58 MOQ: 500 Meters
Key Specifications
Get Latest Price
LED Light Source:
5050SMD
Type:
Flex LED Strips
Input Voltage(V):
DC5V
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen port
Delivery Detail:
Delivery time depends on order quantity.
LED Light Source 5050SMD
Type Flex LED Strips
Input Voltage(V) DC5V
Lamp Power 30W
Lamp Luminous Flux(lm) 600-660lm
Color Temperature(CCT) RGB
Working Temperature(℃) -40, +55
Working Lifetime(Hour) 50000
Lamp Body Material Aluminum
Certification CE, EMC, ETL, FCC, LVD, SAA, UL
Emitting Color RGB
Place of Origin Guangdong, China
Brand Name OEM Optosun
Model Number rgb led strip ws2801 OS-TS510RGB-32-01

Specifications

rgb led strip
1.OEM ODM are acceptable
2.IP67 5V 32IC ws2801
3.Short lead time
4.CE RoHS Approval

addressable rgb led strip ws2801 for decoration





Specifications:

 Item

 Parameter

 Model

OS-TS510RGB-32-01

 Power

7.2W/meter

 Input Voltage

DC5V

 LED Source

5050SMD LEDs

 LED quantity

32 LEDs /meter

 Work current

540-600mA

 Color

RGB

 Beam Angle

120°

 Working Environment

Working temperature:-40°C~+55°C

Working humidity:10%-90%

 Led  Life

>50,000 hours

 Size

W:10mm*P:2mm*L:5,000mm

 Warranty

2 years

 Certificates

CE/RoHS/EMC/SAA/ETL/UL



Advantages of rgb led strip:

1. Using self-produced 5050SMDs ensuring realiable quality and competitive price;

Green: 515-525nm(Single LED Intensity:1800-2200mcd    12*13mil Chip Size)
Red: 620-625nm(Single LED Intensity:600-800mcd    10/11/12mil Chip Size)
Blue: 465-470nm(Single LED Intensity:300-500mcd    12*13mil Chip Size)
2. Using new waterproof glue which is non yellowish and stay flexible even in temepature below zero degree C;

3. Long lifespan, low maintenance cost, energy-saving and environmentally friendly;

4. Anti-UV, NO IR, especially applicable to radiation sensitive objects;

5. Strips can be cut by every 3leds. DIY function;

6. Reliable quality with 2 years warranty;

7.Dimmable function is available;

8.Multi-color remote controller or DMX controller are available;

9.Super brightness. Luminous flux of each led: 18-20lm;

10.Use IC ws2801 to make each LEDs could light different color. even keep the voltage ad current are stable.



Applications of rgb led strip:



Details of rgb led strip:

addressable rgb led strip ws2801 for decoration

addressable rgb led strip ws2801 for decoration



Package of rgb led strip:

addressable rgb led strip ws2801 for decoration

addressable rgb led strip ws2801 for decorationaddressable rgb led strip ws2801 for decoration



Related products:

addressable rgb led strip ws2801 for decoration



For Optosun:

100 workers;

2500 square meter factory;

6 years experience;

3 years vendor of Wal-mart,ISO,CE RoHS certificated.
One hour reach to HongKong, This is how we keep quality and competitives price for global valued customers.

addressable rgb led strip ws2801 for decoration
