Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera

Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera photo-1
US$ 70 - 72 MOQ: 1 Piece
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
SINOVISION
Model Number:
MPT05-CV13F
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name SINOVISION
Model Number MPT05-CV13F
Type Analog Camera
Style Mini Camera
Sensor Other, CMOS, 1.3 Mega Pixel Progressive Scan CMOS
Technology Pan / Tilt / Zoom
Special Features Other, Indoor

Specifications

1/3 1.3 Mega Pixel Progressive CMOS H.264/JPEG Video Compression

Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera



Feathure:

* Mini 4" Color intelligent  speed dome camera


*Unique Plastic Dome casing;


*128pcs preset points



*8 groups trick cruisingeach group can cruise 16pcs preset pointsIntelligent Speed Change0.5°/S-60°/SHorizontal Speed Change0.5°/S-40°/SVertical Speed Change180°Auto overturn360°Constant rotating;


*Horizontal ScanningTwo-point ScanningGuarding Function;



OSD Menu



* Using coaxial transmission mode which lower costs



* Extremely long distance, which use the Normal  wires also can get 300m~500m distance



* Low frequency point to point transmission mode, which avoid CVBS chromaticity crosstalk phenomenon, reflects the strong anti interference ability



* Real time preview, without delay, trailing and lossing image



* Easy and simple to debug & install, which instead of the Old Analog Security System without rewiring.





Specification:



Model

MPT05-CV13F

Mechanical



Preset : 360°/sec

Pan/Tilt Speed

Manual:0.05~360°/sec (proportional to zoom)



Auto Pan : 1~180°/sec

Pan/Tilt Range

Pan :0~360°(Continuous)

Tilt: 0~180°

Preset

128 presets

Other Functions

Auto Flip, Auto Parking, Power up Action etc.

Operation

OSD Menu

English

Communication

RS485

Baud Rate

2400bps,4800bps,9600bps

Protocol

Pelco-P/D, Special protocols available

General

Power Supply

DC12V2A

Work Temperature

-10°C~+50°C

Work Humidity

Max 90%

Help Selection

Ceiling/Wall mounting/Hoisting

Camera

CCD Sensor

1/3”1.0 Mega Pixel Progressive Scan CMOS

Horizontal Resolution

720P

Max Pixels

1280x960

S/N Ratio

52dB(AGC off)

Zoom

6mm MegaPixel fixed lens

Min. Illumination

0.7Lux (Color),0.02Lux(B/W), F1.8, 50 IRE

White Balance

Auto

Shutter Speed

1/50~1/120000sec



Product Image:



 Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera









Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera



 Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera

Certificate:



Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera



Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera

 Production Line:



Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera



48Hours Dark Room Aging Test:



Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera



QA Testing:



Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera





About SINOVISION



Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera



Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera



2013 CPSE SINOVISION Show:



Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera



2014 SINOVISION Intersec Dubai Show:



Dahua 2Megapixel 960P Mini PTZ Indoor Dome CCTV Camera
