AHD 4ch DVR DIY cctv camera system
Feature
*4CH DIY Kit (AHD Camera & DVR) Series
*High Definition AHD1.0MP/1.3MP/2.0MP real-time video
*HD AHD video output, no delay ,lossless, long distance transmission
*Reach 500 meters coaxial cable real-time transmission
*Support low illumination, auto color to black
*4 PCS HD AHD Cameras + 1 PCS 4CH AHD DVR
*1 PCS 4-Way Power Splitter+ 4 PCS 60FT Cable+1 PCS 12V 2A Power Adaptor For Camera
Specification
| Model NO. | SN-AHD10/13/20-CK04A-4 |
| Package | |
| DVR | 1x4CH AHD DVR |
| Camera | 2x AHD IR Bullet Camera+2x AHD IR Vandalproof Dome Camera |
| BNC Cable | 4x60FT BNC Cable |
| Mouse | 1xUSB 2.0 Mouse |
| Power Cable | 1 PCS Four-In-One Power Splitter Cable |
| Adaptor | 2PCS Power Adaptor,one for Cameras,the other for DVR |
| Camera Type | 1.0MP(720P)/1.3MP(960P)/2.0MP(1080P) Camera Optional |
| Image Sensor | High Definition Image Sensor |
| Effective Pixels | 1280(H)×720(V) , 1MP/ 1280(H)X960(V),1.3MP/ 1920(H)X1080(V),2.0MP Optional |
| TV System | PAL/NTSC |
| Electronic Shutter | 1/25s~1/50,000s , 1/30s~1/60,000s |
| Sync System | Internal |
| Mini Illumination | 0.0Lux |
| S/N Ratio | ≥50dB |
| Scanning System | Progressive Scan |
| Video Output Mode | AHD/CVBS (960H) (BNC) |
| Lens | |
| Focus Length | Board Lens 3.6mm |
| Focus Control | Fixed |
| Lens Type | Fixed |
| Pixels | 2M Pixels |
| Night Vision | |
| Infrared LED | 24PCS |
| Infrared Distance | 20M |
| IR Status | Under 10 Lux By CDS |
| IR Power On | CDS Auto Control |
| Camera Features | |
| Day/Night | Auto (ICR) / Color / B&W |
| OSD Menu Language | EN, CN, DE, FRA, IT, ES,PL, RU, PT, NL, TR |
| White Balance | Auto/Manual |
| Gain Control | Auto |
| Noise Reduction | 3D NR |
| General | |
| Weatherproof Housing | IP66 for bullet camera/IP65 for Metal dome |
| IR Cut Filter | YES |
| Operation Temperature | -10℃ ~ +50℃ RH95% Max |
| Storage Temperature | -20℃ ~ +60℃ RH95% Max |
| Power Source | DC12V±10%, 500mA |
| DVR Type | 4CH AHD DVR |
| System | |
| Operating System | Embedded LINUX |
| Video | |
| Input | 4 Channel, AHD |
| Output | 1 VGA, 1 TV,1 HDMI |
| Audio | |
| Input | 4Channel, RCA |
| Two-way Audio | NO |
| Output | 1 Channel, RCA |
| Alarm | |
| Sensor Input | NO |
| Output | NO |
| Motion Detection | 4 Channel |
| Trigger Events | Recording, Tour, Alarm, Video Push, Email, Screen tips |
| Email Alarm | Send Pieces to The Designated E-mail |
| PTZ | |
| Interface | RS485 |
| Protocol | Pelco-D, Pelco-P, Sony, Sharp, Panasonic, Samsung and Other Protocols |
| Baud Rate | 1200~115200 |
| Address | 0~255 |
| Display | |
| VGA | Resolution: 800×600, 1024×768, 1280×1024,1920×1080 |
| HDMI | Yes |
| Display Split | 4 Channel / 1Channel |
| Privacy Masking | 4 Rectangular Zones (Each camera) |
| OSD | Camera title, Time, Video loss, Alarm, Motion detection, Recording |
| Recording | |
| Video Compression | H.264 |
| Audio Compression | G711A |
| Video Quality | Best/Fine/Normal |
| Record Mode | ManualTimerMotion DetectionSensor |
| Playback & Backup | |
| Sync Playback | 4 Channel / 1Channel |
| Remote Playback | 4 Channel/ 1Channel |
| Search Mode | ALL, Channel, Manual, Time, Date, Motion Detection |
| Playback Functions | Play, Pause, Stop, Rewind, Fast play, Slow play |
| Smart Phone Playback | NO |
| Backup Mode | USB Device/Network |
| Network | |
| Interface | 1 RJ45 10M/100M Adaptive Ethernet Interface |
| Network Functions | HTTP, IPv4,IPv6, TCP/IP, SMTP, DHCP, DNS, PPPOE, DDNS,NTP,DST |
| Web Browser | IE6-11 |
| CMS Software | Support Windows XP /Windows Vista/Windows 7/Windows 8 |
| Extra Stream | CIF/QCIF(1~25fps) |
| Smart Phone | iPhone, ipad, Android ,Android pad |
| Hard Disk Driver | |
| Interface Type | 1 SATA Interface |
| Capacity | Up to 4 TB Capacity |
| General | |
| Language | (Chinese, English, polish, Czech, Russian, Thai, Hebrew, Arabic,Bulgarian, Persian, |
| Germany, France, Portugal, Turkey, Spain, Italy, Hungary, Romania, Korean) | |
| USB Interface | 2 USB 2.0 Interfaces |
| Power Supply | DC12V/2A |
| Working Environment | -10~55℃/10~90% |
How can I get some samples?
We are honored to offer you samples.But free sample is not available to new scustomer,when you become our VIP,you will have this privilege.
What's your MOQ?
No MOQ for any sample,at least 50pcs/model after sample order.
Is OEM,ODM service available?
Yes,we providevariety OEM Services,like printing logo,Label,Packing box,when reach 50pcs/Mode. ODM will be based on the quantity.
Payment:
1.Price Terms:EXW,FOB SHENZHEN(Shipping cost are quoted under your requirement)
2.Payment terms:L/C,T/T(USD/RMB).Western union.Paypal etc.
Delivery Time:
Sample order,3-7days after payment cleared;Bulk order,7-14 days after payment cleared.(Working days upon receipt of deposit)
Warranty:
1.Warranty: 18 Month for DVR & NVR ;24 Months for Cameras;
2.The warranty starts from the delivery date from our factory;
3.During the warranty,any defective products can get repaired or replaced for free;
4.The warranty is unavailable for those products which are broken by the violence,the carelessness,
repaired or altered without the authorization.
5.Provide 7*24h services.
