Specifications:
Materials |
Chassis Material:double hot dip galvanized RHS |
Frame Material:sandwich boards | |
Brake |
double axle electric brakes on all wheels and one hand brake on draw bar |
Suspension |
Roll Rocker tandem spring 6 plates |
Wheels & Tyre |
Five 195R14C tyres and 15’ aluminum alloy rims including a spare wheel |
Floor |
Wood |
Windows & Doors |
Front Window(mm):1100x450 double glazed acrylic pane window with roller blind , fly screen ,and gas struts,it can stop at any positions. |
|
Side Windows(mm):900x500(three) &900 X300(three) double glazed acrylic pane window with roller blind ,fly screen,and gas struts | |
Back window(mm): 900X300(one)double glazed acrylic pane window with roller blind and fly screen | |
|
one Ventilating Fan (FIAMMA brand)in front and the other Ventilating Fan on the top of bathroom One thermovent at the back of fridge and the other thermovent at the back of electricity distribution box | |
Caravan Door(mm):1750 x 625(with inductionlight) | |
Supporting Wheel |
One jockey wheel andfour lifting jacks |
Plug&Light&Petro Reflectors |
Plug :5 plugs in caravan One Water supply system control panel with three switches( Battery switch, water gauge and water pump) Two 240v external power points (one for input &the other for output) |
|
2 white width lights & 3 yellow Petro Reflectors on each side 2 white width light & 2 white Petro Reflectors in front 2 groups of tail lights | |
|
interior lights:eight12v lights (kitchen, dining/ bed areas and bathroom)with switch one 12vexternal LED light | |
Internal Features |
Luxury European Style Furniture with lockable handles chrome storage baskets in cupboard top cupboards |
Insulated roof & walls | |
Kitchen:basin, tap ,Gas detector | |
Large Sofawith storage boxes can convert to a double bed | |
Bunk beds | |
fridge(80L,475mmx528mmx640mm) WAECO brand,12v&240v function | |
Air Conditioner(VACDER brand, 240v)with heating and cooling function | |
water tanks:two 80L clean water tanks under chassis& 12v pumps in cupboard | |
shower and portabletoliet | |
A big rechargeable battery , One rectifier transits 240v to 12v | |
|
Optional |
65L Dometic fridge:add 1000$. |
110L Dometic fridge:add 1300$ | |
Demetic air-condition: add 1300$. | |
Dayrelex air-condition:add 1300$. | |
|
Fiamma Awning: 2.58M-US$948, 3.5M-US$1148, 4M -US$1303, 4.5M-US$1633 Awning made in China(Feet): 7 -US$688, 8-US$695, 9-US$712, 10-US$736 |
|
Vacuum THETFORD cassette toilet:add 1600$. |
Dimensions |
Overall Dimension(L x W x H :mm): 7600X2280X2600 |
Body Dimension(L x W x H :mm):6200X2280X1960 | |
Length of draw bar(mm): 1400 |
