Deluxe Angle Load Horse Floats With Sunshade and Tyre

Deluxe Angle Load Horse Floats With Sunshade and Tyre thumbnail-1
Deluxe Angle Load Horse Floats With Sunshade and Tyre thumbnail-2
Deluxe Angle Load Horse Floats With Sunshade and Tyre thumbnail-3
Deluxe Angle Load Horse Floats With Sunshade and Tyre thumbnail-4
Deluxe Angle Load Horse Floats With Sunshade and Tyre photo-1
Deluxe Angle Load Horse Floats With Sunshade and Tyre photo-2
Deluxe Angle Load Horse Floats With Sunshade and Tyre photo-3
Deluxe Angle Load Horse Floats With Sunshade and Tyre photo-4
US$ 100 - 20,000 MOQ: 1 Set
Key Specifications
Get Latest Price
OEM No.:
3HAL
Max Payload:
2500 KGs
Size:
5925 x 2290 x 2600
Contact Supplier Request Quote Chat Now
Shandong Standard Trailer Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
OEM No. 3HAL
Max Payload 2500 KGs
Size 5925 x 2290 x 2600
Place of Origin Shandong, China
Brand Name STD
Model Number STD-3HAL-L500

deluxe angle load horse floats with sunshade and tyre

deluxe angle load horse floats with sunshade and tyre

Detailed parameter

Model STD-3HAL-L500
Materials Chassis Material: double hot dip galvanized RHS (3.5mm-4.0mm)
  Frame Material: double hot dip galvanized RHS (2.5mm)
  Body Panel: galvanized sheet (1-1.5mm)
  Roof: Special molded FRP 3mm
Brake double axle electric brakes
Drawbar Drawbar Checker Plate 1.2mm aluminium
  Drawbar Safety Chain two & Bracing Wheel one
Suspension Roll rocker tandem spring 8 plate
Axles Two special trailer axles 50*50mm
Wheels & Tyre Five 205R14 tyres and 14’ aluminum alloy rims including a spare wheel
Rubber Matting 18mm special plywood for floor& ramp door
  Rubber Matting For Inner Side Panel           6mm Rubber Matting
  Rubber Matting For Floor & Ramp Door     17.5mm anti-slip rubber sheet
Windows& Doors Front Window (mm) 1220*610mm
  Side Windows   6       Drop-down windows 3
  Vents     two large size upturning ventilation windows
  Rear Upper Door (mm) 1980*1065 Strut & High-intensity anti-rust strut
  Ramp Door (mm) 2030*1210
  Side Door (mm)   1730*615
  Hinges for Rear Upper Door   special 6mm diameter copper hinges
Supporting Wheel Swing-able knight supporting wheels to make parking safe and reliable
Lights& Retro Reflectors Trailer Plug       Seven-prongs plug
  Rear Lights brackets aluminium
  LED interior lights, two small LED sidelights, two LED combination taillights
  Retro Reflectors 8
Auxiliary Fittings Cupboard   Front
  Horse Protection Frame fully padded
  Horse Ring     7
  Saddle Rack   in saddle box(1200mm height for 3 saddles)
  Rug Rack       Side
  Saddle Box   One
Dimensions Body Dimension (L x W x H: mm) : 5075 x 1980 x 2230
  Inner Dimension (L x W x H: mm) : 5025 x 1930 x 2155
  Overall Dimension (L x W x H: mm): 5925 x 2290 x 2600
  Length of Tone (mm):   850
Empty Weight 1900 KGs
Carrying Capacity 2500 KGs



Our engineers from Australia

deluxe angle load horse floats with sunshade and tyre

Customers visited our factory

deluxe angle load horse floats with sunshade and tyre

Customers' use case--horse float in Australia

deluxe angle load horse floats with sunshade and tyre

The letter from customer

deluxe angle load horse floats with sunshade and tyre
