Manufacturer SC Bare Fiber Optic Adapter for Splice & Test
SC Bare Fiber Optic Adapter for Splice & Test manufactured by ANC International Co., Limited is used to temporarily connect to bare (un-terminated) fiber to meet test, service and communications requirement. The SC Bare Fiber Adapter features a unique holding mechanism that clamps down onto the fiber to hold it secure during testing or polishing.
Specification
Small loss, excellent reflex inhibition
Size precision, matching
Easy to operate and intuitive, can be used by the naked eye
Can be re-used
Single mode and multimode fiber can be used
Square and Round type SC Bare Fiber Adapter optional
Accord with Telcordia, ANSI, the TIA / EIA, NTT, JIS and other standards
Features
SC Bare Fiber Adapter with Compact design
RoHS compliant for all SC bare fiber adapter material
Usage
Single-disk fiber optic testing
Fiber optic cable repair
Temporary fiber splice
Technical Data
Type |
Data |
Unit |
Adapter Type |
SC/LC/FC/ST |
|
Insertion Loss |
≤0.2 |
dB |
Interchangeability |
≤0.2 |
dB |
Repeatability |
≤0.1 |
dB |
Temperature |
-40~+85 |
℃ |
1PC per small bag; Delivery is within 3 working days since order confirmation.
Small orders to ship by Express;
Bigger orders to ship by Air or Sea
1. 100% factory test before shipping
2. Laser label or Customized lable can be provided;
3. Good at OEM & ODM production;
4. Professional sales
5. Fast response and delivery
6. Quality Guarantee: Lifetime;
ANC produces and sells high quality SC Male-LC Female fiber optic adapter and many other male-female and female-female hybrid adapters.
