Band Saw For Metal Cutting BS-912GR
Features:
1. Maximum capability 9"
2. The belt gear of it has four cutting speeds
3. The quick clamps can be rotated from 0° to 45°
4. Can be used both vertically and horizontally
5. High-capacity due to controlled by motor
6. The falling speed of saw bow is controlled by hydraulic cylinder. The base of the roller can be move freely.
7. Has a sizing device (the machine will automatically stop after sawing materials)
8. With power break protection device, machine will power off automatically when the rear protective cover is opened
7. With cooling system, can prolong the service life of saw blade and improve the precision of work piece
9. Equipped with a block feeder (with fixed sawing length)
10.The bow can be swiveled between 45° and 90°,gear driven
Specification:
Model |
BS-912GR |
|
Capacity |
Circular @ 90° |
229mm(9”) |
Rectangular @90° |
178x305mm(7”x12”) |
|
Circular @45° |
150mm(6”) |
|
Rectangular @45° |
127x150mm (5”x6”) |
|
Blade speed |
@60Hz |
38,78,115MPM |
@50Hz |
31,65,95MPM |
|
Blade size |
27x0.9x2655mm |
|
Motor power |
1.1kW 1.5HP(3PH), 1.5KW 2HP(1PH) |
|
Drive |
Gear |
|
Packing size |
160x60x115cm |
|
N.W./G.W. |
220/260kg |
|
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
