MD618A Electric Surface Grinding Machine
Specifications:
Model |
MD618A |
|||
Working table |
Table Size (L× W) |
mm |
460×180 |
|
Max movement of working table(L× W) |
mm |
500×190 |
||
T -Slot number×width |
mm |
1×14 |
||
Grinding head |
Max distance from spindle center to table surface |
mm |
335 |
|
Wheel Size(Outer diameter×width×Inner diameter) |
mm |
φ180×13 ×Φ31.75 |
||
Wheel speed |
50HZ |
r/min |
2850 |
|
60HZ |
3440 |
|||
Feed amount |
Longitudinal speed of working table |
m/min |
3-20 |
|
Cross feed of working table |
Continuously (Variable Transmission) |
mm/min |
150 |
|
|
Intermittently (Variable Transmission) |
mm/times |
0-5 |
||
|
Per revolution on handwheel |
mm |
2.5 |
||
|
Per graduation on handwheel |
mm |
0.02 |
||
Vertical feed on handwheel |
Per revolution |
mm |
1.25 |
|
Per graduation |
mm |
0.01 |
||
Commutation feeder |
Total input power |
w |
150 |
|
X- feeder output speed |
R/min |
0-225 |
||
X- feeder size |
mm |
280×130 ×120 |
||
Y- feeder output speed |
R/min |
0-120 |
||
Y- feeder size |
mm |
280×130 ×120 |
||
Motor power |
Spindle motor |
kw |
1.1 |
|
Coolant pump motor |
w |
40 |
||
Working precision |
The parallelism of working surface to base level |
mm |
300:0.005 |
|
Surface roughness |
μm |
Ra0.32 |
||
Weight |
Net |
kg |
667 |
|
Gross |
kg |
767 |
||
Overall dimension(L×W×H) |
mm |
1550x1150 x1590 |
||
Package dimension(L×W×H) |
mm |
1000x1150 x1760 |
||
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It
as all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
