1 Type Y31200E lengthening gear hobbing machine, gear cutting
machine, hobbing machine
Specifications
piece dia.1500/2000
2.Max.machining modular12/16
3.Worktable dia. 1000
4.Worktable loading capacity 3
5.Max.hob260
Parameter:
Type | Y31200E |
piece diameter(with rear column/no rear column) | 1500/2000mm |
Max.machining modular(steel/cast iron) | 12/16mm |
Max.machining width(center distance≥400) | 450mm |
Max.hob diameter/length | 220mm |
Work table diameter | 1000mm |
Hob principal axis Rotate speed/grade | 16~125rpm/7 |
Max.axial movement Value hob principal axis | 100mm |
Taper bore of the spindle | Morse 6 |
Distance from hob Centre to worktable | 220~680mm |
Distance from hob Centre to worktable | 120~1100mm |
Distance from outer support Surface to worktable centre | 500~900mm |
Worktable aperture | 220mm |
Max.swivel angle of tool post | ±60 |
Worktable loading capacity | 3 |
New workpiece axis diameter | 60mm |
Main motor | 11kw/1440rpm |
Machine outline dimension L×W×H | 4400×2040×2500mm |
Weight(about) | 14300kg |
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
