WC67Y-100T/3200 Hydraulic Plate Bending Machine
Feature:
WC67Y series hydraulic sheet metal press brake for sale, with higher labor productivity and higher working precision, the machine adopts steel plate welded structure, with sufficient strength and stiffness, using different shapes and down mold can be bent into various shapes of the workpiece, It can bend complex shape of the workpiece after several bending steps, It also can punch.
1. Hydraulic transmission ,stable working ,easy operation, low noise, safe and reliable.
2. In cylinder there are mechanical stops to ensure repeat positioning is accurate when slider get the bottom dead point, in order to ensure the uniformity of bending angle.
3. The use of German technology to eliminate internal stress.
4. slide stroke can be adjusted, and has inching, semi-automatic and other action norms, using the jog specification can be easily tryout and adjustment.
5. Double cylinders simultaneously, operating balance, convenient and secure.
6. It has delayed time function at lowest dead point to ensure accuracy of the workpiece.
Specification:
Model Number |
WC67Y-100/3200 |
Pressure |
1000KN |
Worktable length |
3200mm |
Distance between columns |
2500mm |
Depth of throat |
320mm |
Slide Stroke |
150mm |
Max height between worktable and ram |
330mm |
main motor |
7.5kw |
Weight |
6400kg |
Dimension (LxWxH) |
3390x1600x2450mm |
The Tengzhou Datong Machine Tool Co.,Ltd. is one of the leading manufacturers and exporters of machine tools in Shandong Province in China. We are specialized in the manufacturing of the XW series Universal Lifting Platform Milling Machine,the XQ series Universal Swivel Head Milling Machine,the ZX series Universal Drilling and Milling Machine,the ZQ serie Universal Radial Drilling Machine.Varies models of Hydraulic Machine,Automatic Boring Drum Machine,HD2006-A laser beam level truck locator and hydraulic auto-maintain equipment.
Datong has the right to import and export,and gained CE and ISO9001 System Certification.It has all the integration of R&D,manufacturing & processing,management & marketing,technical service,import & export and into one.At present,we have more than 300 employees,among them,160 have college education which more than 50 persons hold junior,middle and senior professional post .More than 200 sets of main production equipment and testing equipment.The products are widely exported to Europe,South-America and Southeast Asia and other countries and regions.
"Honesty Basic,Quality First"is the company's purpose,"continuous progress to satisfy the requirements of the customers" is the quality policy.
The Tengzhou Datong Machine Tool Co.,Ltd.sincerely wishes to cooperate with friends at home and abroad to realize mutual development!
