Home > Products > Wooden & Granite ACP > Wooden Grain Aluminum Composite Panel
Wooden Grain Aluminum Composite Panel
- 20000 Square Meter / Square Meters per Month
- Shanghai
- T/T L/C D/P D/A
Product Details
Brand Name: | Sky Rainbow | Model Number: | wooden-PVDF | ||
Usage: | Outdoor | Function: | Anti-Static, Antibacterial, Fireproof, Mould-Proof | Surface Treatment: | Other, NANO-PVDF coated |
Packaging Details
< 1 > Wooden box Or Nude packing ; < 2 > Weight: 5.5kg/M2 baesd on 0.5/4mm thickness ; < 3 > Standard size: 1220x2440mm ; < 4 > Qty/20'fcl: 4mm/2380M2 , 3mm/2977M2 with Wooden box ; < 5 > Qty/20'fc: 4mm/3600M2 , 3mm/5000M2 by nude packing
Product Description
Specifications
1) thickness:1~8mm2) Width:1000~2000mm
3) PVDF:20 years (PPG Paint)
4) Core:Unbreakable, Firproof A2
5) CE; ISO;Green Leaf
A) Front : aluminium alloy sheet coated with fluoro-carbon resin (PVDF) or polyestor resin(PE) B) Core: nontox low density polyethylene or Firproof core C) Back: aluminium alloy sheet coated with polyester resin painting D) Surface coating thickness: 38μ±1μ in four coating E) Aluminium alloy: 3003 H24 F) Sheet thickness: 0.21mm,0.3mm,0.4mm,0.5mm |
A) Thickness: 3mm,4mm,6mm,8mm,10mm B) Width: 1220mm,1250mm,1500mm,1570mm,1800mm,2000mm(max) C) Length: 2440mm,3050mm,3200mm( max:6000mm) D) Weight: 5.5kg/sqm baesd on 0.5/4mm thickness E) Standard size:1220*2440mm F) Qty/20'fcl:4mm/2380sqm; 3mm/2977sqm G) Non-stanard size are available according to requirement |
A) West Europe standard ( Germany DIN Standard); B) The EAST Europe standard ( Russian standard ); C) The commonweathlth standard (U.K BS Standard ); D) The North America ASTM standard; |
A) Light weight,flat surface and high strength
B) Excellent heat insulation ,sound insulation,fire-resistance,acid-resistance,alkali-resistance,weatherproofness and non-resonance
C) Various uniform colors
D) Rbright ,elegan and magnificent,fit for various designs
E) Kynar 500 PVDF resin feature strong chemical resistance,unique colors can be easily maintained
A) May be widly used in gallaies,exhibition,saloons,stores,offices,banks,hotels,restaurants and apartments
B) An ideal decorative materials for buildings
C) An ideal outer and inner walls
D) Kitchen cabinees,billboards,signboards,tunnels,subway,interiors
E) Cellings,eaves,galleries,balconies,partitions,interior decorations
F) Telephone tooths,vehicle bodies,yachts,industrial usage etc.
The composite structure of SkyRainbow® results in an impressive strength-to-weight ratio, even when comparing large panel sizes. Despite its low weight, which makes Sky Rainbow ® easy to transport and handle in the factory and on site, its rigidity and high strength make the panels keep their shape and remain flat, even when exposed to extreme temperature changes. Comparison of thickness and weight of panels with equal rigidity |
|
Company Profile
Established in 2001, Jiangyin Tianhong Decoration Material Co., Ltd. is a specialist manufacturer of aluminum composite panels, wall coverings and borders. With the ability to manufacture more than 2,000,000 square meters of aluminum-plastic composite panels for a wide range of building applications, and in as many colors and textures every month, we have emerged as a leader in our field.
Our skilled R&D team uses CAD to design products, and can turn out 10 new models annually. Additionally, due to our large production capability, we can easily fill large orders with ease, and accept orders for as few as 100 panels. In either case, our strategic location allows for delivery in just 25 days.
Durable and easy to install, our products are gaining popularity worldwide. As they are a suitable replacement for wood, pre-painted and an excellent insulator, they are also considered to be an environmentally friendly product.
In a bid to provide a better service to our customers, Jiangyin Tianhong Decoration Material Co., Ltd. provides support for insurance, shipping, customs, quality inspections, export documentation, promotion catalogs and on-the-spot repair. For more information about any of our series, or to place your requirement, please feel free to contact us directly. We hope to receive your detailed inquiry soon, and are looking forward to having the chance of cooperating with you in the near future.
