SPX-830GS Automatic custom made stable three face
sticker labeler
Introduction
1.The whole machine adopts imported servo control system which is enable the running stable operation, high speed, advanced touch humanmachine interface friendly, simple operation,
complete functions, has a wealth of online help function
2.Adopts imported electrical components of world famous brand, which ensure the stable,
reliable
3.The general shape of the bottle separating device and double chain correction device ensure neutral, to special elastic top pressure equipment to ensure that the bottle shaped any diameter of the material stability without replacement parts, rapid positioning adjustment
4.A machine can complete the three types (round bottle, flat bottle, Square bottle) automatic
side labeling specifications
5.Delivery, correction, pressure and speed automatic synchronous automatic synchronization tracking, which is enable to make adjustment is more rapid and simple
6.Automatic sensing, have nothing item without labeling, and without label automatic stop or
alarm automatic detection function, prevent leakage and waste
7.Optional configuration (with code machine) can be online to print production date and batch number, reduce the bottle packaging process, improve production efficiency
8.The special report of calibration device, labeling, firm, smooth without wrinkles, improving packaging quality
9.The machine can connection production line, optional connection pipeline, can also be
equipped with the material collecting disk, collecting, sorting and packaging for finished products
A: Host using the company's two cutting-edge technology:
1) Double standard delivery pressure rollers, which will help improve the accuracy of labeling.
2) Due to the label under the rolling of initiative compression rolle before labeling, helping to eliminate wrinkles, improve labeling quality, to the exhaustion of the last label.
3) Two stage clutch with spring sending label, added with belt-type brakes, realizing hi
gh-speed constant tension label transmission.
B: Explaination of performance: 1) Since the machine uses a combination of cutting-edge technology and high-performance execution unit - Ultra small inertia servo motor. System makes closed-loop control of servo motorsthrough the programmable logic controller Professional from German company Siemens, using advanced affinity human-machine interface system to achieve human-computer dialogue. Host controls process label transmission speed up to 0.01 m / min , rather than the general machine's 1 m / min. whereas in terms of speed, this machine uses Panasonic 750W high power ultra-small inertia servo motor, speed can be adjusted to a wide range between 0.5 to 40 m / min to suit the customer's production speed, so as to achieve true high-speed labeling.
Model / technical parameters |
SPX-830GS |
Labeling capacity(pcs/min) |
40-200 b/min |
Labeling accuracy(mm) |
±1.0mm |
Label size |
(L)20-300mm (H)10-280mm |
Material size |
(W)40-180mm (H)40-190mm |
Roll inside(mm) |
Φ76mm |
Roll outside diameter(mm) |
Φ350mm |
Machine size (mm) |
(L)3600*(W)1700*(H)1600(mm) |
Power supply |
AC220V 50Hz/60Hz 3000W |
Other series of labeling machine
Guangzhou Sipuxin Light Industry Machinery Co., LTD., a professional technology -oriented machinery manufacturer integrating research, development, production, sale, engineering installation, technical consultation and after-sales service. We are mainly engaged in production and installation of equipment for pharmacy, food, cosmetic, chemical industry, etc., providing one-stop prompt service for customers.
Holding the enterprise concept of providing more considerate service, we grasp equipment production standards, control equipment quality through technical innovation and provide high quality production equipment for customers.
The main products of our company include: vacuum homogenizing emulsifiers, high shear liquid detergent mixers, reserve osmosis ion water devices, various water injection, liquid and ointment semi-automatic and automatic filling production lines, round and flat bottles automatic and semi-automatic labeling machines, perform whole–set production lines, laboratory equipment, flow lines, etc.
Professional design experience, leading manufacturing technology, excellent equipment quality and sincere operation concept are the basis for our company to develop. We will continue implementing the concept as usual. Welcome new and old customers to visit and instruct us.
Dear customers,
Thanks for your visiting,The following are we offer :
1.Customized production line designing.
2.Competitive price .
3.Strictly control in machine producing .
4.Check carefully before delivery .
5.Good logistic control and service support.
6.Technical support, we can assemble the line in your factory with all the cost on your account.
7.Lifelong aftersale service in technical .
8.Package : wooden case
9.Delivery day : 15-30 days after deposit
10.payment terms : 40% deposit after sales confirmation , 60%before delivery
11.Validity : 20 days from the quotation date ,as all cost in china increasing.
