Wireless Ccd Mini Box Camera

Wireless Ccd Mini Box Camera thumbnail-1
Wireless Ccd Mini Box Camera photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Ruiye
Model Number:
RY-5001
Contact Supplier Request Quote Chat Now
Shenzhen Rui Ye Electronic Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Ruiye
Model Number RY-5001
Style Box Camera
Sensor CCD
Technology Pinhole
Special Features Waterproof / Weatherproof
Type Other, Video Camera

Specifications

1. 1/3sony,1/4sony,1/3sharp,1/4sharp ccd
2. 420/480/520/540TVL
3. Standard 3.6mm lens
4. waterproof

1.Pice-up Device:SUPER HAD CCD

2.Horizontal Resolution:420TVL

3.Power Supply:12VDC,Auto white balance

4.minimal illumination: 0.8lux /F1.2, S/N Ratio ≥48db

signal1.0vp-p750hms

6. Electronic shutter 1/50(1/60)-1/100000 Sec

Image sensor

CCD

1/4 SHARP

1/3SHARP

1/4SONY

1/3SONY

Signal System

PAL/NTSC

Horizontal Resolution

420TVL,480TVL,520TVL,540TVL

Level Synchronous Frequency

P:15.625KHZ/N:15.734KHZ

Clock Frequency MHZ

P:19.3125/N:19.0699

Scanning Systerm

2:1 interlace

Minimum Illumination

OLUX(IR LED ON)

Synchronous System

Internal, Negative sync

S/N Ratio

More than 48dB

Auto Electronic Shutter

P:1/50~1/100,000sec;N:1/60~1/100,000

Gama Characteristic

0.45

Video Output

1Vpp 75Ohms

Auto Gain Control

Auto

Effective pixels

PAL:500(H)X582(V), NTSC:510(H)X492(V)

lens

 3.6mm

Led lights



IR distance



Voltage

12V±10%DC,

Operation Temperature

-10~+45°C





Remark:

  1. vibration-proof
  2. 1/3  sony,1/4sony,1/3sharp,1/4sharp optional.
  3. Resolution 380/420/480/520/540TVL optional.
  4. we can print your beautiful logo on the case.
  5. we can design and print packing box according to your inquiry.
  6. stick your model No.&series No. on  the cameras and packing box.
wireless ccd mini box camera
