RY-8003 Mini 420 Color CCD CCTV Security Dome Video Camera

Name: RY-8003 Mini 420 Color CCD CCTV Security Dome Video Camera
Brand: Ruiye
SKU: 123402385
Availability: InStock

Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

Ruiye

Model Number:

RY-8003

Shenzhen Rui Ye Electronic Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name Ruiye

Model Number RY-8003

Type Other, Analog Camera, Video Camera

Style Dome Camera

Sensor CCD

Technology Infrared

Special Features Vandal-proof

Specifications

1.Pice-up Device:SUPER HAD CCD
2.Horizontal Resolution:420TVL
3.Power Supply:12VDC
4. moveable case, wide angle lens

Features:

420 Color CCD CCTV Security Mini Dome Auto Video Camera

Description:
Features & Specifications:

Multi-purpose all directional dome casing - you can rotate it in all directions after installation.
This dome casing enable you to do it hassle -free. The camera can be rotated like a ball in a socket.
Please note that this camera is not water reistance thus it is suitable for indoor use only.

- Image Device: 1/3" SONY Color CCD
- TV System: PAL/NTSC
- Validity pixel: PAL:500*582, NTSC:510*492
- Horizontal definition: 420 TV Lines
- Scan frequency: PAL/NTSC: 50Hz/60Hz
- Minimum illumination: 0Lux /F1.2
- Video Out 1.0Vp-p,75 OHM
- S/N Ratio 48db
- Automatic conversion on Daytime or night
- Daytime (color) / Infra-Red Night (B/W)
- Power Supply: 12V DC 1000mA
- Viewing Angle: 90 degree
- 3.6mm lens
- Infrared Leds: 24 Leds
- Night Vison Distance: 15-20m
- Housing material: Plastic
Package Content:

- CCD Outdoor 24 IR Camera SONY 1/3" x 1
- Usage Manual x 1
