ZH-GZF500 Powder Screen Machine

ZH-GZF500 Powder Screen Machine photo-1
US$ 19,000 - 45,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
Chemical, Food, Other, Medical, Chemical, Food, Machinery & Hardware, Medical
Packaging Type:
Bottles, Cans
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Chemical, Food, Other, Medical, Chemical, Food, Machinery & Hardware, Medical
Packaging Type Bottles, Cans
Packaging Material Other, Powder
Automatic Grade Automatic
Driven Type Electric
Voltage 1P 220V 50-60Hz
Power 2000W
Place of Origin Zhejiang, China
Brand Name ZHONGHUAN
Model Number ZH-GZF500
Dimension(L*W*H) 2400*800*1700
Weight 600kg
Certification SGS
After-sales Service Provided Engineers available to service machinery overseas

                                  Automatic Powder Filling Machine for bottles and cans





Description:

The machine is suitable for packing powdery &grainy product, for instance, milk powder, monosodium glutamate, solid beverage, icing sugar, dextrose, feed, coffee, solid medicament, powdery & grainy additive, dye, etc.



Features

1.Chinese /English touch screen and HMI, PLC control system, auger is drived by servo motor.

2.Equipped with automatic can/bottle feeding system, implement to the functions of no-can-no-filling.

3.Open-door hopper, a frame type machine be designed the humanization to easily wash. Reasonable mechanical structre, easy to change size parts and clean up.

4.The functions of over-weight warning, error message display and failed packs detecting & deleting, which never let any reject to pass through, ensure the packing quality.

5.Max. 10 recipes can be saved for later using.

6.Have the functions of can support, vibration and dust extraction.



Main Technical Parameter:

Model

ZH-GZF500

Volume

50g-250g

Accuracy

≤±0.3-1%(According to packing weight and product specs

Hopper Volume

30Liter×2

Packing Speed

 25-30 can/min(one head), 40-50 can/min(two heads)

Supply Power

1P  220V  50-60Hz  2000W

Compressed Air

0.2m³/min 6-8kg/m²

Dimension

2400×800×1700mm(L×W×H)

Net Weight

600Kg



v

Terms and Conditions:



Payment: 30%TT in advance, 70%TT before machine ship out;



Delivery time: around 45 days to leave our factory after advance payment and samples



Warranty: one year after shipment.



Packing: according to export standard







See following photos of introduction of the machine.

ZH-GZF500 Powder Screen Machine







Welcome to email us to know more advantages of our machine, we will send you videos and detailed photos together . which will surprise and satisfy you.
