850/900/1800/1900MHz HIGH QUALITY AND LOW PRICE SMS GSM FWP NO NEED PSTN LINE

Brand: DOBRY

Model: F801

Item: 850/900/1800/1900MHz HIGH QUALITY AND LOW PRICE SMS GSM FWP NO NEED PSTN LINE.

Key words: wireless phone, GSM cordless phone, GSM FWP,GSM  fixed wireless phone, Wireless home phone, GSM handset, GSM FCP fixed cellular phone, cell phones.

GSM  SIM card cordless phone also named cordless phone supporting SIM card. It can access to GSM mobile cellular networks directly. No wiring, install

 quickly and easily. The method of operation like use mobile phone. It has caller ID, call record, dial local numbers

without dial the area code as well as hands-free function, which greatly facilitates the use.

It is ideal to adapt to the needs of modern wireless communication solutions. Stylish appearance, compact design,

 built-in antenna, large capacity phone book, large volume, high tones.

Features:

1. support the GSM network:dual band 900/1800Mhz, quad band 850/900/1800/1900MHZ; (optional)

2, support high-quality voice services (FR, EFR, HR speech coding);

3, support emergency call service;

4, support caller ID, call forwarding, call waiting, call hold, three-way calling and other  supplementary services;

5, Short Message.

6, Phone book

7,Support DTMF second dial

8, user penalization volume setting;

9, supports polyphonic ring tones choice;

10, LCD display: 128 × 64 dot matrix. provide LCD display back light;

11, TNC antenna interface: indoor antenna;

12, Integrated antenna (optional);

13, Receive Sensitivity: better than-103dBm;

14, back up battery. when the battery is low and there is AC power to charge the battery automatically.

15, provide a variety of security solutions, such as network lock, lock card, modem card interlock (optional).

16, SIM card interface: standard 6 PIN SIM card interface.

17,Support multi-language: Chinese, English, Spanish, Portuguese, Russian, Arabic, French, Thai. (Optional)

18, alarm,calculator,Calandar.

19, accept OEM.

Hardware specifications:

1, Networks support: GSM900/1800MHz; GSM850/900/1800/1900MHz

 Frequency ranges:
 A) GSM 850                                   GSM 1900:
 I) Transmission: 869.2 ~ 893.8MHz      I) Transmission: 1, 930 ~ 1, 990MHz
 Ii) Reception: 824.2 ~ 848.2MHz         Ii) Reception: 1, 850 ~ 1, 910MHz
 B) GSM 900:                                  GSM 1800:
 I) Transmission: 890 ~ 915MHz           I) Transmission: 1, 710 ~ 1, 785MHz
 Ii) Reception: 935 ~ 960MHz              Ii) Reception: 1, 805 ~ 1, 880MHz

2, External Interface:

USB, for data configuration.

TNC antenna interface: can be installed indoor antenna.

Integrated antenna (optional).

Power Interface: single connector

SIM card interface: standard 6 PIN SIM card interface

3, Maximum transmit power:850/900MHz: 33 +2 dBm,1800/1900MHz: 30 +2 dBm

4, Receiver sensitivity:Better than-103dBm

5, Power Specifications : AC: 100V ~ 240V,DC: 5.00V, 0.8A

6, Rechargeable Battery

Type: Lithium Battery

Capacity: 3.6V 800mAh (1000 mAh optional)

Typical talk time: (based on network environment)

3 hours (battery capacity 800 mAh),4 hours (battery capacity of 1000 mAh)

Typical standby time: (based on network environment)

90 hours (battery capacity of 800 mAh),110 hours (battery capacity of 1000 mAh)

7, Dimensions (L*W*H)

stand: 160*45*22 mm  Base:100*92*65mm

8, weight (with battery):300g

9, LCD Display:128 *64 dot matrix

10, Temperature

Working temperature: -10 ℃ ~ +45 ℃

Storage temperature: -20 ℃ ~ +60 ℃

11, Relative humidity:5% to 95%

12, Placement:Flat

Pictures:

   1 unit/box, 20 units/carton. 7KG per carton. Carton size: 34*29*24CM
