Home > Products > New Products > Deck Cargo Barge
Deck Cargo Barge
- 10 Set / Sets per Month
- Xingang
- T/T L/C D/P D/A
Product Details
Type: | Bulk Carrier | ||||
Fuel Type: | Diesel | Condition: | New | Draft: | 24.4m |
Year Built: | new | Place of Origin: | Tianjin, China | Brand Name: | GTcargo barge |
Product Description
We Glorytang Group invested a shipyard which can built Cargo Barge according to customers inquiry .
GENERAL DESCRIPTION The vessel is an unmanned dump barge suitably equipped for carrying deck cargo for unrestricted services. The barge is all welded steel construction. It has flush deck and two skegs. The main hull is divided by 8 transverse W.T. bulkheads and 3 longitudinal Bulkheads into 33 compartments. |
CLASSIFICATION The vessel shall be constructed and fully equipped in accordance to ABS Class. |
PRINCIPAL PARTICULARS Length O.A. : 91.50m Breadth MLD : 24.40m Depth MLD : 5.50m Deck loading : 7T/M2 |
OUTFITTINGS 1) Sideboard: L: 82.35m×21.96m×3.6/3.0m Plate: 8mm Longitudinal: L100X75X7/L150X90X9 Stays: H150x150x10 2) Mooring bollards: Mooring bollards of 300 N.B. Heavy Duty Pipe are fitted on main deck as shown on drawing with 14mm double plate to be fitted. 3) Anchor winch One unit of 10T diesel driven winch to be fitted onboard. Anchor Wire Rope 200m x 37.5mm dia. Anchor wire rope to be supplied and installed. Anchor One unit of 1950Kg stockless bower anchor with 6m of 32mm Dia. Anchor chain. |
