Japan Technology 4x2 Platform Emergency Rescue Truck 120hp Good Quality

Name: Japan Technology 4x2 Platform Emergency Rescue Truck 120hp Good Quality
Brand: ISUZU
SKU: 123363429
Availability: InStock

US$ 22,000 - 27,000 MOQ: 1 Unit

Key Specifications

Fuel Type:

Diesel

Emission Standard:

Euro 4

Condition:

New

Hubei Heli Special Automobile Manufacture Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

any port in China

Delivery Detail:

Delivery time depends on order quantity.

Fuel Type Diesel

Emission Standard Euro 4

Condition New

Transmission Type Manual

Dimensions (L x W x H) (mm) 7490x2300x2500

Place of Origin Hubei, China

Brand Name ISUZU

Model Number HLQ5070TQZQ emergency rescue truck

Product Description

Vehicle parameters
Vehicle Model		HLQ5070TQZQ	Vehicle Brand	HELI
Overall dimensions		7490×2300×2500mm	Curb weight	4170kg
Manufacturer	Hubei Heli Special Automobile Manufacture Co.,Ltd

Chassis parameters
Chassis model		QL1070A1KAY	Chassis brand	ISUZU
Overall dimensions		6645x1880x2160mm	Wheel base	3815mm
Front/rear wheel track		1504/1425mm	Front/rear suspension	1015/1815mm
Approach/departure angle		24/14°	Maximum speed	105km/h
Chassis Manufacturer		QingLing Motors (Group) Co., Ltd.
Cab	Configuration	600P,single row cab,allowable 2 passengers,car interior, air conditioner, USB radio interface, with oil brake vacuum booster pump
	Color	White,other color is optional
Engine	Model	4KH1-TCG40
	Emission	Euro 4
	Type	4 cylinders, in-line, 4-stroke,water-cooled,turbo inter-cooling,4-valve ,diesel engine
	Rated power	120hp,rated power speed 3400rpm
	Displacement	2999ml
	Manufacturer	Isuzu Engine (Chongqing) Co., Ltd.
Tire	Size	7.00-15 10PR nylon tire
	Number	6+1 nos
Front axle	2.5 tons
Rear axle	4.8 tons
Drive form	4X2
Suspension	Multi leaf springs
Rated voltage	24V,DC
Transmissions	Isuzu MSB five speed transmission,5 speed forward 1 reverse.
Steering device	Power assisted steering
Steering wheel	Left hand drive
Selective configuration
If there is a slight change in the chassis parameters above,please take the actual product as the standard

Wrecker structure parameters
		Color and Logo	Optional
Standard configuration	Light duty:chassis,sub frame,floor with hook, auxiliary wheel, bundling belt, automatic slide, lights,small wheel cover,lifting 3 tons,winch 4 tons. Heavy duty:chassis,sub frame,double hoist, crane, hydraulic legs
Selective configuration	Hydraulic clamp (12T lever), electric saw (400WX2) with motor.

MOQ,payment terms,delivery terms,price
MOQ	One unit
Payment terms	T/T 30% down payment, 70% balance after inspection before delivery
	L/C is optional
Inspection	Buyer's agent or third party inspection agency,the cost is paid by the buyer
Delivery term	20 days from down payment
Documentation	Maintenance manual
	User manual
	Packing list
	Commercial invoice
	Certificate of origin is optional
	Spare parts list for purchase is optional
Standard tools	With standard tools for chassis and wrecker structure
Packing	The main vehicle nude and covered with wax, attached parts and tools put into standard export box
Other requirements		Please fill in here
FOB			USD
CNF/CIF			USD	Shipment
Because exchange rate and ocean freight may be changed in near future,so the price is only valid for 15 days. Please confirm the price again with our company before placing the order,thanks.
