Vehicle parameters | ||||
Vehicle Model |
HLQ5090GXWE |
Vehicle Brand |
HELI |
|
Overall dimensions |
6995×2285×2650mm |
Curb weight |
4605kg |
|
Tank dimensions |
3800×1450×1450mm |
Tank volume |
6000L |
|
Manufacturer |
Hubei Heli Special Automobile Manufacture Co.,Ltd |
|||
Chassis parameters | |||||
Chassis model |
EQ1090T9ADJ3AC |
Chassis brand |
DONGFENG |
||
Overall dimensions |
6695x2180x2350mm |
Wheel base |
3800mm |
||
Front/rear wheel track |
1750/1586mm |
Front/rear suspension |
1180/1715mm |
||
Approach/departure angle |
22/13° |
Maximum speed |
80km/h |
||
Chassis Manufacturer |
Dongfeng Automobile Co.,Ltd |
||||
Cab |
Configuration |
Single row cab,air conditioner,allowable 3 passengers,cab can be flipped |
|||
Color |
White,other color is optional |
||||
Engine |
Model |
CY4102-E3C |
|||
Emission |
Euro 3 |
||||
Type |
4 cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling,diesel engine |
||||
Rated power |
120hp,rated power speed 2800rpm |
||||
Displacement |
3856ml |
||||
Bore x stroke |
102x118mm |
||||
Manufacturer |
Dongfeng Chaoyang Diesel Power Co. Ltd. |
||||
Tire |
Size |
7.50R16,steel wire tire |
|||
Number |
6+1 nos |
||||
Frame |
192mm |
||||
Brake |
Air break, electronic flame out, exhaust brake |
||||
Fuel tank |
100L,steel |
||||
Front axle |
2.4T |
||||
Rear axle |
4.2T |
||||
Drive form |
4X2 |
||||
Rated voltage |
24V,DC |
||||
Transmissions |
5 speed forward 1 reverse. |
||||
Steering device |
Power assisted steering |
||||
Steering wheel |
Left hand drive |
||||
Selective configuration |
Air Conditioner, Cummins engine B140 33(140hp) |
||||
If there is a slight change in the chassis parameters above,please take the actual product as the standard | |||||
Vacuum sewage suction tank structure parameters | ||||
Tank dimensions |
3800×1450×1450mm |
Tank volume |
6000L |
|
Tank material |
Carbon steel |
Tank thickness |
6mm |
|
Color and Logo |
Optional |
|
|
|
China WEILONG vacuum pump | ||||
Model |
50QZXDH-68/7000 |
RPM |
800r/min |
|
Flow |
68L/s |
Pressure |
7000Pa(93%) |
|
Power |
5kw |
Weight |
50kg |
|
Standard configuration |
Chassis,sub frame,vacuum sewage tank,oil water separator, water gas separator, hydraulic cylinder for unloading device, domestic vacuum pump, pressure gauge,suction hose, gravity flow valve, connected device,observation tube, automatic anti overflow valve, hydraulic suite,rear door hydraulic opening. |
|||
Selective configuration |
Italy BP vacuum pump,Italy Hydraulic Motor |
|||
Italy BP vacuum pump | ||||
Model |
MEC9000 |
RPM |
1400r/min |
|
Flow |
107L/min |
Pressure |
174bar |
|
Power |
30kw |
Weight |
145kg |
|
Italy Hydraulic Motor | ||||
Code |
6080200141 |
Model |
KM30.73-RO |
|
R.P.M |
1000r/min |
Capacity |
73,82L/min |
|
Output |
17KW |
Torque |
136Nm |
|
MOQ,payment terms,delivery terms,price | |||||
MOQ |
One unit |
||||
Payment terms |
T/T 30% down payment, 70% balance after inspection before delivery |
||||
L/C is optional | |||||
Inspection |
Buyer's agent or third party inspection agency,the cost is paid by the buyer |
||||
Delivery term |
20 days from down payment |
||||
Documentation |
Maintenance manual |
||||
User manual | |||||
Packing list | |||||
Commercial invoice | |||||
Certificate of origin is optional | |||||
Spare parts list for purchase is optional | |||||
Standard tools |
With standard tools for chassis and vacuum sewage suction tank structure |
||||
Packing |
The main vehicle nude and covered with wax, attached parts and tools put into standard export box |
||||
Other requirements |
Please fill in here |
||||
FOB |
USD |
||||
CNF/CIF |
USD |
Shipment |
|
||
|
Because exchange rate and ocean freight may be changed in near future,so the price is only valid for 15 days. Please confirm the price again with our company before placing the order,thanks. | |||||
1, attached parts and tools put into standard export box.
2, vacuum sewage suction truck will be cleaned and covered with wax before delivery.
3, vacuum sewage suction truck will be covered by waterproof cloth at the departure port.
4,Roll-on/Roll-off ship or bulk cargo ship is optional according to the customers’ requirements.
5,some small vacuum sewage suction truck can be put into container according to its overall dimensions.
Hubei Heli Special Automobile Manufacture Co.,Ltd is a professional vacuum sewage suction truck manufacturer in China. Supply ability of vacuum sewage suction truck is 200 units per month. We have a perfect quality inspection system for vacuum sewage suction truck . welcome to our company to purchase the vacuum sewage suction truck .
1, How to purchase the vacuum sewage suction truck from your company?
You can choose the model from our website, also you can tell our sales manger your specific requirements and we will recommend the suitable model to you. After confirming the model and price, we can sign the contract.
2,How to ensure product quality?
Firstly,we passed the international quality system certification. Secondly, Alibaba Group has conducted field certification for our factory. Finally,You can entrust third party individuals or organizations to inspect our products before delivery.
3, How to visit your factory?
After you arriving at China, you can fly to Wuhan airport. Wuhan airport is located in Wuhan City, Hubei Province. Our driver will meet you at Wuhan airport and take you to our city by car.
