calcium silicate board

Specifications

calcium silicate board
Experienced Manufacturer
High strengh,Low Thermal conductitive
1000*600,610*150mm
ISO9001:2008

calcium silicate board

It is mixed with Xonotlite and reinforced glass fibre with high service temp. (1050 celsius),good heat insulation, low bulk density, high strength, good durability and so on.

Product characteristics:

²        Good durability, can bear high temperature  within the limit of continuous heat load,

²        Low thermal conductivity, in the whole range are used with unmatched adiabatic performance.

²        Light weight, high strength. It is the highest in these hard thermal insulation products.

²        Better durability, use for a long time without powder.

²        Construction with ordinary carpenter applicability, tools can be optional cut products.

²        Used safety, hygiene. Excluding asbestos, sulfur, chlorine such poisonous substances.

²        Fear water, but after drying also can be used.

 HCS Physical Performance Index

Items	Unit	HCS-170	HCS-220	HCS-270
Bulk Density	Kg/m3	170(±10%)	220(±10%)	270(±10%)
Pressure Strength	MPa	≥0.40	≥0.50	≥0.60
Flexural Strength	MPa	≥0.30	≥0.35	≥0.40
Thermal Conductive	W/m.k	≤0.048 +0.00011t	≤0.050 +0.00011t	≤0.056 +0.00011t
Temp. limit	degrees	1000	1050	1050
Linear Shrinkage	%	≤1.50 (1000,3hrs)	≤1.50 (1000,3hrs)	≤1.50 (1000,3hrs)



Block Sizes and Dimensional Tolerances

Length(±3mm)	Width(±3mm)	Thickness(+2mm,—1.5mm)
610	303,300,150	25—140
600	300	25—140
400	250	25—140
1000	500	25—140
1200	600	25—140

We also supply special size and type.
