Home > Metallurgy, Mineral & Energy > Steel & Products > Steel Round Bar > High Carbon High Chromium Cold Work Tool Steel Skd 11 Steel Rule Die

High Carbon High Chromium Cold Work Tool Steel Skd 11 Steel Rule Die

Name: High Carbon High Chromium Cold Work Tool Steel Skd 11 Steel Rule Die
Brand: Fuyuan
SKU: 123344809
Availability: InStock

High Carbon High Chromium Cold Work Tool Steel Skd 11 Steel Rule Die thumbnail-1

High Carbon High Chromium Cold Work Tool Steel Skd 11 Steel Rule Die thumbnail-2

High Carbon High Chromium Cold Work Tool Steel Skd 11 Steel Rule Die thumbnail-3

High Carbon High Chromium Cold Work Tool Steel Skd 11 Steel Rule Die photo-1

High Carbon High Chromium Cold Work Tool Steel Skd 11 Steel Rule Die photo-2

High Carbon High Chromium Cold Work Tool Steel Skd 11 Steel Rule Die photo-3

US$ 1,000 - 3,000 MOQ: 1 Metric Ton

Key Specifications

Get Latest Price

Steel Grade:

Alloy Steel

Standard:

AISI, ASTM, BS, DIN, JIS

Dimensions:

Round50--500mm

Contact Supplier Request Quote Chat Now

Huangshi Fuyuan Import And Export Trading Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai shenzhen zhenjiang ningbo wuhan huangshi

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Steel Grade Alloy Steel

Standard AISI, ASTM, BS, DIN, JIS

Dimensions Round50--500mm

Place of Origin Hubei, China

Brand Name Fuyuan

Model Number 1.2379 / Cr12Mo1V1 / D2 / SKD11

Technique Other, Forged, Forged or Rolled

Application Tool Steel Bar

Alloy Or Not Is Alloy

Special Use Mold Steel

Type Alloy Steel Bar

Product Introduction

SKD11 is high carbon and high chromium, ledeburitic 12 % Cr alloyed cold work tool steel. Properties: excellent abrasion resistance due to a large volume of carbides in the microstructure, high cutting ability with edge holding properties, high compression strength, excellent deep harden ability and toughness properties, dimensional stability during heat treatment, high res-istance to softening at elevated temperatures. Suitable for nitriding and electrical discharge machining.

Specification

*Item*
Size (can be customized)	Round	Dia 12mm-500mm	Length 2000mm-5800mm
	*Flat (when forged, production width is 4 times than thickness)**	Thickness 12mm-400mm
		Width 50mm-800mm
Chemical Composition (can be customized)	DIN 1.2379	C:1.50-1.60, Si:0.10-0.40, Mn:0.15-0.45, Cr:11.00-12.00, V:0.90-1.10, Mo:0.60-0.80, P:≤0.030, S:≤0.030
	AISI/ASTM D2	C:1.40-1.60, Si:0.10-0.60, Mn:0.20-0.60, Cr:11.00-13.00, V:0.50-1.10, Mo:0.70-1.20, P:≤0.030, S:≤0.030
	JIS SKD11	C:1.40-1.60, Si:≤0.40, Mn:≤0.60, Cr:11.00-13.00, V:0.20-0.50, Mo:0.80-1.20, P:≤0.030, S:≤0.030
	GB Cr12Mo1V1	C:1.40-1.60, Si:≤0.60, Mn:≤0.60, Cr:11.00-13.00, V:0.50-1.10, Mo:0.70-1.20, Co:≤1.00, P:≤0.030, S:≤0.030
Process	EAF+LF+VD+ESR+FORGED/ROLLED+Heat Treatment (Annealed,A Normalized, Q+T)
Heat treatment	Normalized ; Annealed ; Quenched ; tempered
Surface Condition/Treatment	Black surface; Grinded/Peeled ; Machined;Turned/Bright
Inspection	100% Ultrasonic according to the test standards:SEP1921-84,CLASS C/c or D/d
Payment Terms	T/T;L/C (30% advance payment by T/T, and 70% should be paid against the color scanned copy of BL by T/T or irrevocable L/C at sight)
Trade Terms	FOB; CIF; CFR
Packing	Standard seaworthy packing or as customer required
Shipping Marks	As Buyer/Seller's option. N/M means no marks.
Invoicing	According to acctural weight (25 tons). If the acctural weight ≥ 25 tons, pls fill less to the seller for the over weight according to the PI price.
Size tolerence	0/+2mm for bright / grinded / machined surface, 0/+4mm for black / peeled surface.
Length tolerence	10% shorter length should be allowed.
Quantity tolerence	-10%/+10% for total quantity.
*Heat Treatment*
Annealing	800 - 850 °C
Hardness after Annealing	Max. 250 HB
Stress relieving	650 - 700 °C
Hot forming	1050 - 850 °C
Hardening	1020 - 1080 °C
Quenching media	Oil, Salt bath ( 220 - 250 °C or 500 - 550 °C )Air or compressed air
Hardness after quenching	63 - 65 HRC
Hardness after tempering	100 °C: 63 HRC, 200 °C: 61 HRC, 300 °C: 59 HRC, 400 °C: 58 HRC.
Applications	High performance blanking, punching, stamping and cutting tools and dies up to 6 mm sheet thickness, thread rollings,chasers and dies, precision blanking dies, longitudinal and circular shear blades for plastic, paper and metal, cold form-ing and bending tools, tools for drawing, deep drawing and cold extrusion, hobbing tools, woodworking tools, milling cutters, reamers, broaches, pressing tools for the ceramics and pharmaceutical industries, cold piercers, measuring inst-ruments and gauges, rolling cutters and shaping wheels, cold pilger mandrels, beading, flanging and straightening rolls,plastic injection moulds, especially cutting tools of austenitic material when nitrided.

Product Show

Why Choose Us

About us

1, the company professional to produce and RD more than 100 kinds and 1000 sizes of die / mould / tool steel products more than 10 years;Rich technology strength & strong processing strength & advanced production equipment & complete test instrument & rigor quality management.

Quality control

2, Acceptable materials; UT test; After annealing ,steels are held for a suitable time in sands and cooling slowly; Machining; Tolerance control; Strictly testing; Certification: Mill Certificate Test or third party inspection institution.

Service

3, Sample free provided from inventory; MOQ is 1 metric ton; Reliable quality; Competitive price; In seaworthy packing; Excellente service; Reply within 24 hours.

Product Processing
