Home > Furniture > Lab Furniture > Lab Bench > Laboratory Equipment Fume Hood Fume Extractor

Laboratory Equipment Fume Hood Fume Extractor

Name: Laboratory Equipment Fume Hood Fume Extractor
Brand: Beta
SKU: 123341705

Laboratory Equipment Fume Hood Fume Extractor thumbnail-1

Laboratory Equipment Fume Hood Fume Extractor thumbnail-2

Laboratory Equipment Fume Hood Fume Extractor photo-1

Laboratory Equipment Fume Hood Fume Extractor photo-2

Negotiable MOQ: 1 Unit (Price negotiable depending on order volume and customization)

Key Specifications

Get Latest Price

Material:

Metal

Metal Type:

Other, Galvanized steel

Size:

1200/1500/1800*850*2350mm

Contact Supplier Request Quote Chat Now

Guangdong Beta Laboratory Furniture Company Ltd.

6Yrs

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Material Metal

Metal Type Other, Galvanized steel

Size 1200/1500/1800*850*2350mm

Place of Origin Shanghai, China

Brand Name Beta

Model Number Beta-D-01-01

2015 Hot Sale Fume Hood

1.Standard Features

• Fluorescent light (bulbs included)

• Sash stop

• PP/ PVC duct

• Epoxy resin Powder Coated air foil with drip trough

• Clear view panel

• Black Powder Coated horizontal and vertical sash

• Stainless steel baffle screen

Note: Sash enclosure optional

2.PRODUCT OF FUME HOOD

3.SPECIFICATIONS

Product Name	High Quality Laboratory Furniture Acid Digestion Fume Hood Laminar Flow Hood
Size	1200(W)850(D)2350(L) mm; 1500(W)850(D)2350(L) mm; 1800(W)850(D)2350 (L) mm.
Color	Custom-made
Casework	1.2mm thickness of cold-rolled steel plate, after acid washing, phosphide and electrophoresis, sprayed with good quality anti-corrosion static coating.
Inside Lining	4mm thickness of Compact.
Worktop	1)19/20mm thickness EPOXY, Black Color 3)20mm thickness GRANITE , 4)25mm thickness STAINLESS STEEL 5)19mm thickness WILSONART CHEMSURF/POSTFORMED MALAMINE (FORMICA) Black , Gray Color 6)20mm thickness CERAMIC, Black Color
Sash	6mm of tempered glass.
Sash Handle	2mm Cold-rolled steel powered with epoxy coating.
Illumination	with not less than 300 Lux 30W fluorescent lamp set
Cup sink	Oval shaped PP Cup sink
Water Tap	Molded in one piece copper water tap, epoxy powder coating surface with a ceramic valve.
Valve	1Water valve. (by custom)
Exhausting Duct	Anti-corrosion PP/PVC duct
Plinth	With 1.5mm thickness of cold-rolled steel plate, after acid washing, phosphide and ‘dian yong’, sprayed with good quality anti-corrosion static coating.
Technical specification	Noise: less than 60db (International standard), Face velocity: 0.5m/s, 220V
Function	With an intelligent automatic delay protection device to exhaust residual corrosion air completely and prolong the service time of fume cupboard.
Socket	4 Electric sockets, (By custom)
Exhaust fan	not include exhausting duct &exhaust fan, will provide after receiving the detailed design of exhaustion duct.

4.MORE CHOICE

Different kinds of structure and material for choices,as follows:

1. Floor Mounted Full Steel Workstation Laboratory Furniture

2. Floor Mounted Full Wood Workstation Laboratory Furniture

3. C-Frame Steel-Wood Workstation Laboratory Furniture

4. C-Frame All Steel Workstation Laboratory Furniture

5. H-Frame Steel-Wood Workstation Laboratory Furniture

6. H-Frame All Steel Workstation Laboratory Furniture

7. Stainless Steel Workstation Laboratory Furniture

5.MAIN BUSINESS LINES

A.Laboratory Planning, Designing, Production, Integration, Installation, Consultation & Project Management.
B.Lab Furniture Designing, Development, Manufacturing, Installation. Commissioning & Service.
C.CAV/Two-State/VAV UBC Laboratory Air Flow Control System.
D.Laboratory Furniture, Fume Hood, Enclosure & Ventilation Product
E.Laboratory Specialty Gas Pipe and Gas System
F.Comprehensive Supply of Lab Accessories.

6.ORDERING PROCESS

7.MANUFACTURE&PACKAGE

8.CETIFICATE

9.CONTACT

Telephone:	0086-757-8778-1160/ 0086-757-8778-1161
Fax:	0086-757-8778-1160
Factory Address:	No. 968 Pengqing Road Huaqiao Town, Kunshan
Foshan Branch:	Room 1003, Business Blg. Garden Hotel, No. 39 Guanghai Avenue, Xinan Town, Sanshui District, Foshan City, Guangdong Province, PRC
Zip:	200000
Country/Region:	China (Mainland)
