2014 Fast Fill and Sew Bagging Machine SW-620

2014 Fast Fill and Sew Bagging Machine SW-620 photo-1
2014 Fast Fill and Sew Bagging Machine SW-620 photo-2
2014 Fast Fill and Sew Bagging Machine SW-620 photo-3
Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Application:
Food, Other, Food, Machinery & Hardware, industry
Packaging Type:
Stand-up Pouch, Bags, Pouch, Case
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhongshan
Delivery Detail:
Delivery time depends on order quantity.
Condition New
Application Food, Other, Food, Machinery & Hardware, industry
Packaging Type Stand-up Pouch, Bags, Pouch, Case
Packaging Material Plastic
Automatic Grade Automatic
Driven Type Mechanical
Voltage 200V
Power 2.2KW
Place of Origin Guangdong, China
Brand Name SMART WEIGH
Model Number SW-P620
Dimension(L*W*H) L1250mm*W1600mm*H1700mm
Weight 800kg/900kg
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

This series vffs machines is SIEMENS PLC control with stable reliable biaxial high accuracy output, with 80 bag/min.

Application:



Smart weigh SW-P620/720 is SIEMENS PLC control with stable reliable biaxial high accuracy output and Machine adjustments via full feature operator HMItouch-screen, high-speed capable of bag-making a maximum of 60 bags per minute.Film-pulling with servo motor double belt,This machine can make large bag stand pillow bag; pillow bag with Gusset;Square bottom bag;Specially for salads.



2014 Fast Fill and Sew Bagging Machine SW-620



 2014 Fast Fill and Sew Bagging Machine SW-620





Features:



1).Attractive bag type to satisfy your high demand.
2).It completes bagging,sealing, date printing, punching, counting automatically;
3).Film drawing down system controlled by servo motor.Film rectifying rectifying deviation automaticlly;
3).Famous brand PLC. Pneumatic system for vertical and horizontal sealing;
4).Easy to operate, low maintenance, compatible with different internal or external measuring device.
5).The way of bag making: the machine can make pillow-type bag and standing bag according to customer’s requirements.



Specification:





Model

SW-P620
SW-P720

Packing speed

50 bag/min
45 bag/min

Bag size

(L)20-400mm (W)100-300mm

(L)20-450mm (W)140-350mm

Bag style

Pillow-type bag, standing-bevel bag, punch bag

Max packaging film width

Max 620mm

Max 720mm

Thickness of film

0.04-0.09mm

0.06-0.12mm

Air consumption

0.8Mps  0.6m3/min

0.7×105Pa  200L/min

Main power/voltage

2.2KW/ 200V 50Hz

4.5KW/220V  50-60Hz

Dimension

L1250mm*W1600mm*H1700mm

(L)1360×(W)1630×(H)1900mm

The weight of switchboard

800kg

900kg





Optional device:



1).Thermo transfer printer
Function: easy to change printing content and layout on the screen

2).Bag former
Function: making different bag width

3).Gusset device
Function: making gusset bag

4).Euro hole
Function: making holding hole

5).Easy open
Function: easy to open bag

6).vibration device
Function: for stickly and Expanded Food, easy for droping down

7).PE foil sealing device
Function: special for PE foil packing

Optional Filling Systems:

1).Fits most fillers for dry and frozon applications:
2).Combination weighers
3).Combination scalesAuger fillers
4).Cup fillers
5).Linear scales

Bag type selection

2014 Fast Fill and Sew Bagging Machine SW-620

2014 Fast Fill and Sew Bagging Machine SW-6202014 Fast Fill and Sew Bagging Machine SW-620




Machine dimension layout:



2014 Fast Fill and Sew Bagging Machine SW-6202014 Fast Fill and Sew Bagging Machine SW-620


2014 Fast Fill and Sew Bagging Machine SW-620



Packing & shipping:

1. polywood carton
2. 25 days delivery
3. FOB/ CIF terms
