High Performance DU Bushing

High Performance DU Bushing thumbnail-1
High Performance DU Bushing thumbnail-2
High Performance DU Bushing thumbnail-3
High Performance DU Bushing thumbnail-4
High Performance DU Bushing thumbnail-5
High Performance DU Bushing thumbnail-6
High Performance DU Bushing photo-1
High Performance DU Bushing photo-2
High Performance DU Bushing photo-3
High Performance DU Bushing photo-4
High Performance DU Bushing photo-5
High Performance DU Bushing photo-6
US$ 0.05 - 0.05 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Zhejiang, China
Brand Name:
DEWIN
Model Number:
Custom Made
Contact Supplier Request Quote Chat Now
Shaanxi Dewin Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Zhejiang, China
Brand Name DEWIN
Model Number Custom Made
Type Sleeve
Material Steel
Our company

We produce self-lubricating bushing (oilless bushing) since 2004.

Our factory located in Jiashan, Zhejiang and 30 employees with the building area of 1500 square meters.

Product Description

SF1 Steel + Teflon(PTFE) self-lubricating bushing

Generally, it has 3~4 layers:

1.Outer suface plating: Sn, Cu, or Zn (For anti-corrision and rust)

2.Metal sheet (Base)

3.Bronze layer (As the glue between lubricating layer and metal sheet)

4.lubricating layer (PTFE, POM, Bronze, Graphite)

 High Performance DU Bushing High Performance DU Bushing
 High Performance DU Bushing High Performance DU Bushing



Drawing



 High Performance DU Bushing

Technical Data

Performance index

Data

Max load capacity

Static load

250N/mm²

Dynamic load

140N/mm²

Max sliding speed

Dry friction

2.5m/s

Oil lubrication

5.0m/s

MaxPV value limit

Dry friction

3.6N/mm² m/s

Oil lubrication

50N/mm²  m/s

Friction Coefficient

Dry friction

0.08~0.20

Oil lubrication

0.02~0.07

Working temperature

-195°C~+280°C

Thermal conductivity

42W/m k

Coefficient of thermal expansion

11x0.0000006/k



Packing&Shipping
 High Performance DU Bushing High Performance DU Bushing
 High Performance DU Bushing High Performance DU Bushing



Inner Packing:

Plastic film tubes(OD over 25mm)& Plastic bags(OD less than 25mm)

Carton:

360*360*240mm
360*360*180mm
360*240*180mm

Pallet:

18 cartons/pallet (1.2*0.8*1=0.96 m3),about 800 kg/pallet

Delivery:

23 days(General type 15 days),at Shanghai port

Our Services



Partner Services:

  • Product industry-related market investigation.
  • Providing office and sales staff as your branch in China.
  • Co-ordination of sales & marketing locally.
  • Organizing, monitoring and following up of attending in exhibitions.
  • Breakdown service case by case and general problem solving locally.
Our Factory
 High Performance DU Bushing High Performance DU Bushing
 High Performance DU Bushing



Exhibition

  High Performance DU Bushing
