Help CenterEnvironment Friendly Led Outdoor Lighting With Long Lifetime
Related Products
-
Portable Led Street Light Module Super Led LightingUS$ 81.6 - 96MOQ: 1 Piece -
High Power ul Led Street Light IP65 WaterproofUS$ 52.7 - 62MOQ: 1 Piece
-
Modern Appearance Dimmable Led Street Light Energy SavingUS$ 176 - 207MOQ: 1 Piece
-
High Lumen Led Street Light Retrofit With High QualityUS$ 195.2 - 244MOQ: 1 Piece
-
Competitive Price Led Modules for Street Light Low Installation CostUS$ 78 - 91MOQ: 1 Piece
Best selling 5 years warranty LED light
led outdoor lighting
360 All for One Design
With one design,it gives solution for all your needs in public illumination,industrial illumination and commercial illumination,simply by changing different mountings for street light,tunnel light,canopy,high bay light,park light and flood light!
Superior Performance
World Top Nichia LED
With efficiency up to 140lm/w
Match with high efficiency driver up to 94%,pfo>0.9
Together with the special designed thermal management,achieve superior system efficiency at least 110lm/w.
Reliable Quality Assurance
Aluminum housing and high heat conductive alloy modular bar in a special designed air flow thermal management system
With built in protection for short circuit/overload/over voltage/over temperature
Backed up 5-5-10 years warranty
| model | system power | modular | color | optics | voltage | options |
|
SP-1016 Street light |
40w 60w 100w 120w 150w 200w 250w |
2B 2 modular bar 3B 3 modular bar 4B 4 modular bar 5B 5 modular bar 6B 6 modular bar 7B 7 modular bar |
40k 4000k 50k 5000k 57k 5700k |
B1 BAT1 B3 Bat360 RB Rack B S1 Bat Shape1 S3 Bat Shape3 17 170D 80 80D 40 40D 20 20D |
MV 100-240/277V HV 347/480v1 DC 12/24vDC2 |
LED brand3 N Nichia S singbee
Housing Color4 SLV silver BLK black BRZ bronze WHI white
Others5 DIM dimming PH photocell MS motion sener WM wall mount |
1.Covers 200~480V,not available on 40w
3.Nichia is standard LED brand,other brand such like CREE is available on request
4.Silver is standard housing color,other color that is not shown here can be customized on request
5.This is mainly the accessories to go with the light,there is more available,for detail please see our 360 wing catalogue
Performance
| system power | modular |
4000k system lumen4 |
x dimension |
net weight |
|
40w 60w |
2 Bar |
4814 lm 6687 lm |
272mm/10.7" |
7.6kg/16.76 lb 7.6kg/76.67 lb |
100w |
3 Bar | 11313 lm | 343mm/13.5" | 8.9kg/19.62 lb |
| 120w | 4 Bar | 13743 lm | 414mm/16.3" | 10.2kg/22.49 lb |
| 150w | 5 Bar | 17067 lm | 485mm/19.1" | 11.2kg/24.69 lb |
| 200w | 6 Bar | 22779 lm | 556mm/21.9" | 13.4kg/29.54 lb |
| 250w | 7 Bar | 27913 lm | 627mm/24.7" | 14.5kg/31.974 lb |
