Low Bed Semi Trailers Used For Equipment Transport

Name: Low Bed Semi Trailers Used For Equipment Transport
Brand: ketian
Availability: InStock

FOB Price

US$ 8,000 - 15,000 / Set

1 Set(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Parameter

Trailer Model	heavy duty low bed trailers
Overall Dimension(Lx W x H)(mm)	*1300030001700*
Platform size (Lx W x H)(mm)	*1300030001250*
Function	Transport excavator
Tare Weight(KG)	6350
Loading Weight( KG)	50000
Total Weight(KG)	60000
Axle Brand	BPW
Axle Number	2/3/4
Wheelbase(mm)	6260+1310+1310
Suspension system	Common Mechanical suspension (Air suspension )
Steel Spring	10/10/10 leaf spring suspension
The material of Main beam	the height of the beam is 500 mm, upper plate is16mm, down plate is 18mm,middle plate is 10mm.
Platform plate	3mm Diamond plate
Tire Type and quantity	1200-20 12units
Traction Pin	90mm 50mm
Spare Wheel Bracket	2 pieces
Tool Box	1 Standard
Landing Gear	Standard 28Ton
Brake system	Dual Line braking system ,none ABS.
Brake air chamber	Two double and two single chamber
Electrical system	1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness)
	Tail lamp with turn signal, brake light & reflector, side lamp etc.
	One set 6-core standard Cable.
Side Guard	According to customer’s requirement
Painting	Depends on customers requirements
Packing	Polish with wax before shipping
