2 Axles 16t fuwa typesemi trailer mechanical suspension

Mechanical Suspension Spare Parts

1.Front Hanger

2.Radius Rod Assembly

3.Equalizer

4.Equalizer Hanger

5.Leaf Spring

6.Rear Hanger

Features of mechanical suspension

• 9 to 18 t capacity.

•12mm*100mm*12pcs or 13mm*90mm*13pcs leaf spring.

• 2-axle,3-axle and 4-axle.

• Reliable proven design.

• High strength components.

• Light weight design.

• Simple maintenance procedures.

• Components to achieve extended service life.

• Go with both round and square axles

Types of trailer suspension

#.American style suit suspension

#.American style inverse suspension

#.German style suspension F

#.German style suspension B

#.Japanese style suspension

#.Light suspension

#.Air suspension

#.Bogie suspension

Mechanical Suspension More Information ( Just for Reference)

1.The front, middle and rear spring hangers are made of high tensile low alloy steel plates (pressed and welded into structure) stronger but lighter than the old type.

2.The new design prevents the spring from shifting in a side way during running, The 90mm wide steel spring is made of high quality material.

3. The antifriction block (welded) is made of high tensile steel plate material (or #20cast steel) .

4. Its angle is in line with the unfolding direction between the steel plate spring and the antifriction block of the rocker arm.

5. The angle of the torque arm is scientifically adjusted. It can efficiently reduce the instant sliding distance between the tires and the ground, effectively lower friction of the tire, and increase the tire service life.

6.The torque arm bushing is made of urethane rubber. It has a buffering function to the instant abrasion in sliding shift of the tire.

7.The above features, plus a correct installation, reliably guarantee the verticality between the axle and the king pin, effectively remove the phenomena of offset abrasion and gnawing, and make the tire wearing even

Packaging

Related products

Company information

Jinan Ketian Auto Parts Co.,Lt is located in Jinan,Shandong province and our factory is at Liangshan county,which is a leading manufacturer and specializes in suspension systems,axles,landing gears,fifth wheels,king pins and other trailer parts.
