Chinese XCMG Mini Excavator,Digger Machine XE40 for Sale Prices
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
XCMG Excavator
Model Number:
XE40 Excavator
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Qingdao Lianyungang Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
SHANTUI SD16F Crawler BulldozerNegotiableMOQ: 1 Set -
XCMG ZL30G Wheel Loader 3ton Small Shovel Loader for SaleUS$ 28,000 - 35,000MOQ: 1 Unit
-
Crawler Bulldozer 160hpNegotiableMOQ: 1 Set
-
SHANTUI Types of Bulldozer/Dozer SD16L With Low Price(120kw)NegotiableMOQ: 1 Set
-
CHANGLIN Wheel Loader ZL30H, Avant Loader Small Wheel Loader for SaleNegotiableMOQ: 1 Set
Place of Origin
Jiangsu, China
Brand Name
XCMG Excavator
Model Number
XE40 Excavator
Condition
New
Moving Type
Crawler Excavator
Operating Weight
4050kg
Bucket capacity
0.14m³
Maximum Digging Height
5320MM
Maximum Digging Depth
3600MM
Machine Weight
4050kg
Max Digging Radius
5810MM
Rated Speed
27.1/2200kw/rpm
Certification
ISO,CE
After-sales Service Provided
Engineers available to service machinery overseas
Welcome to Oriemac!
As authorized dealer,we specialize in exporting full kinds of excavatormade by Chinese famous factory,including XCMG,SDLGCHANGLIN,FOTON,LIUGONG,CHENGGONG.
Our company will offer you the best quality products with reasonable
price,quick delivery,and professional after-sale service.
Please don’t hesitate to let us know if you have any questions about
the products.Your reply would be highly appreciated.
Contact Person:Betty Ding
Skype: dgongzuo
Mobile: +86-182-2104-5926
Chinese XCMG mini Excavator,Digger machine XE40 for sale prices:
| Model | XE40C | ||
|---|---|---|---|
| Operating weight | kg | 4050 | |
| Standard bucket capacity | m³ | 0.14 | |
| Engine | Engine Model | / | 4TNV88 |
| Direct injection | / | √ | |
| Four strokes | / | √ | |
| Water cooling | / | √ | |
| Turbo charged | / | × | |
| Air to air intercooler | / | × | |
| No. of cylinders | / | 4 | |
| Rated power/speed | kw/rpm | 27.1/2200 | |
| Max. torque/speed | N.m | 142/1320 | |
| Displacement | L | 2.19 | |
| The main performance | Travel speed | km/h | 4.2/2.6 |
| Swing speed | r/min | 13.5 | |
| Max. gradeability | / | 30 | |
| Ground pressure | kPa | 36.3 | |
| Max.Bucket digging force | kN | 23.2 | |
| Max.arm crowd force | kN | 19.3 | |
| Max.traction force | 33.9 | ||
| Hydraulic system | Main pump | / | Japan nachi |
| Rate flow of main pump | L/min | 1×110+11 | |
| Max pressure of prime relief valve | MPa | 21 | |
| Max pressure of travel system | MPa | 21 | |
| Max pressure of swing system | MPa | 21 | |
| Max pressure of pilot system | MPa | 3.9 | |
| Fuel tank capacity | L | 65 | |
| Oil capacity | Hydraulic tank capacity | L | 70 |
| Engine lubrication | L | 7.4 | |
| A Overall length | mm | 5455 | |
| Overall dimensions | B Overall width | mm | 1650 |
| C Overall height | mm | 2440 | |
| D Overall width of upperstructure | mm | 1500 | |
| E Track length | mm | 2198 | |
| F Overall width of undercarriage | mm | 1635 | |
| G crawer width | mm | 300 | |
| H Dozer black(width/height) | mm | 1650×300 | |
| I Tumbler distance | mm | 1721 | |
| J Crawer gauge | mm | 1335 | |
| K Clearance under counter weight | mm | 578 | |
| L Ground clearance | mm | 350 | |
| M Min.tail swing radius | mm | 1480 | |
| A Max. digging height | mm | 5320 | |
| Working range | B Max. dumping height | mm | 3700 |
| C Max. digging depth | mm | 3600 | |
| E Max. vertical wall digging depth | mm | 2250 | |
| F Max. digging reach | mm | 5810 | |
| G Min. swing radius | mm | 2385 | |
| H Max.dozer lifting height | mm | 255 | |
| I Max.dozer cutting depth | mm | 375 | |
| Angle of arm deflection | Degree | / | |
