JZF-15 1/2'' Ports Pneumatic Angle Seat Piston Valve Two-way

Name: JZF-15 1/2'' Ports Pneumatic Angle Seat Piston Valve Two-way
Brand: MIDCOOL
Availability: InStock

FOB Price

US$ 1 - 1,000 / Piece

1 Piece(Min. Order)

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

JZF-15 1/2'' Ports Pneumatic Angle Seat Piston Valve two-way High quality,low price.
Good discount,best service.

JZF-15 1/2'' Ports Pneumatic Angle Seat Piston Valve two-way

Specification:

PLS CHECK WITH US BEFORE U PAY THE AMOUNT,WE WOULD MODIFY THE PRICE FOR U.

Product Description:

MODEL	JZF-15	JZF-20	JZF-25		JZF-35	JZF-40	JZF-50	JZF-65
Port Size	G1/2	G3/4	G1		G1 1/4	G1 1/2	G2	G2 1/2
Aperture Size (mm)	15	20	25		32	40	50	65
CV	4.9	9.3	22.2		32.1	49.0	60.7	82.2
Working Pressure	0~16Bar
Min.Control Pressure	3.9Bar			4.2Bar	5Bar	4.4Bar	0.4Bar
Piston Diameter(mm)	50			63				80
Material Of Body	Stainless Steel
Material Of Actuator	Polyamide or Stainless Steel
Medium Temperature	-10~180’C
Ambient Temperature	-10~60’C
Medium	Air Gas Water
Actuator Size(mm)	50		63		63 or 100		125
Fluid Direction	A or B
