Best Spherical Roller Bearing 22222 110*200*53mm!

Materials:

1.Material of ring : GCr15,

2.Material of Cage: Steel, brass, polyamide, nylon

3.Material of Roller: chromium steel

External form chnage :

K:        Tapered bore bearing,taper is 1:12

K30:    Tapered bore bearing,taper is 1:30

N:        A snap ring groove on the outer ring

W33:   There are three lubrication groove and three lubrication holes in the outer ring

Clearance:

C0:Norminal clearance,omitted in destination

C2:Less than Norminal clearance

C3:Larger clearance than C0

C4: Larger clearance than C3

Applications:

Papermaking machinery, reducer, railway vehicle axle, gear box bearing, rolling mill rolling mill rolls, crusher, vibrating screen, printing machinery, woodworking machinery, all kinds of industrial reducer, vertical arrange ushering self-aligning bearings.

roller bearing FEATURE:

1. High Quality Steel
2. Advanced Grease Technology
3. High Grade roller
4. Super Finished Raceways - Specially honed to minimise noise and improve lubricant distribution and life.
5. prompt delivery and good service
6. Long service life and competitive price

Design of Spherical roller bearings

MB design

These bearings have a central fixed rib, an one-piece cage guided on the inner ring rib.

MA design

These bearings have a central fixed rib and machined cages quided on the inner ring rib.

C design

These bearings have a central guide rib floating on the inner ring, symmetrical rollerswith largerdimensionssothat the load carrying capacity increases. Special pressed sheet cage. Bearingsofthisdesign areof small and medium sizes.

CA design

These bearings have side shoulders and central guide rib floating on the inner ring, symmetrical rollers with larger dimensions so that the load carrying capacity increases. They also have an one-piece machined brass cages. This design is available for medium and large-sized bearings.

Cages :

Small and medium size spherical roller bearings are fitted with pressed sheet or machined brass cages (Y).Bearings of normal design are fitted with machined brass or steel cages guided on the rollers (M), inner ring (MB) or outer ring raceway (MA).

Glass fibre reinforced polyamide 6.6 cages are success-fully used for small and medium size bearings if the operating temperature doesn't exceed +120?C.

Large-size bearings are fitted with machined brass cages, CA design.

Designs and some technical data are given in table 4.
