Fast Remove and Installation Concrete Batching Plant HZS75(75m3/h)

Name: Fast Remove and Installation Concrete Batching Plant HZS75(75m3/h)
Brand: YUJIE
SKU: 123184627
Availability: InStock

Zhengzhou Changli Machinery Manufacturing Co., Ltd.

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Power Type:

Electric

Place of Origin:

Henan, China

Payment & Shipping

Payment Methods:

Port of Shipment:

China

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Power Type Electric

Place of Origin Henan, China

Brand Name YUJIE

Model Number hzs75

Certification CE

Main Parts:

1. Concrete Mixer: JS1500 (including the steel support)

2. Batching machine: PLD2400

3. Water supply system: Spray mode.

4. Conveyor system

5.Measurement system: measure the aggregate, cement, water, liquid additive.

The electrical system adopts import parts and has credibility performance.

Technical Parameter
Item		Unit	Parameter
Max. Productivity		m³/h	75
Nominal Capacity of Mixer		m³	1.5
Aggregate Storage Capacity		m³	3×12
Rated Delivery Volume of Screw Conveyor		t/h	35
Capacity of Cement Cabin		t	2?00
Mixing Motor Power		kw	45
Lifting Motor Power		kw	18.5
Power of Machine		kw	110
Weight of Machine		t	46
Discharge Height		m	3.8
Overall Dimension (L×W×H)		m	27.1×11.8×19.4
Max. Weights	Aggregate	kg	4000
	Cement	kg	1000
	Water	kg	300
	Additive	kg	50
Measuring Accuracy	Aggregate	%	±2
	Powder	%	±1
	Water	%	±1
	Additive	%	±1
