Small Concrete Mixer Pump(15m3/h--25m3/h)

Name: Small Concrete Mixer Pump(15m3/h--25m3/h)
Brand: YU JIE
Price: Negotiable

FOB Price

Negotiable / Set

1 Set(Min.Order)

Product Details

Condition:	New	Place of Origin:	Henan, China	Brand Name:	YU JIE
Model Number:	XHBT

Models:

XHBT Small Size Aggregate Concrete Pump

HBT Electrical Motor/ Diesel Engine

Products Certificates: ISO9001:2000, SGS test

After-Sale Service:

1. Operator Training;

2. Spare Parts Supply.

Warranty Terms: More than 12 months

Delivery Time: 15~20days after receiving advanced payment.

Zhengzhou Changli Machinery Manufacturing Co., Ltd.-Leading Professional Manufacturer

and Exporter of Concrete Pump

Small Size Aggregate Concrete Pump

Item	XHBT-15SA0708	XHBT-20S/1010	XHBT-25S
Max. Theoretical Throughput (m3/h)	15	20	25
Max. PumpingPressure (MPa)	8	10	10
Max. Theoretical Vertical Conveying Distance (m)	110	140	110
Max. Theoretical Horizontaln Conveying Distance (m)	400	500	400
Max. Aggregate Diamete (mm)	30	30	30
Slump (cm)	12~23	12~23	12~23
Conveying Pipe Radius (mm)	100A/70A	100A/70A	100A/70A
Number of Conveying Cylinder (piece)	2	2	2
Conveying Cylinder Bore X Piston Stroke (mm)	Φ140×700	Φ140×1000	Φ140×1000
Hydraulic Oil Tank Capacity (L)	180	220	240
Feeding Height (mm)	1100	1100	1100
Hopper Capacity (m3)	0.30	0.35	0.35
Power of Main Electric Motor (kw)	30	30	37
Dimension (Length x Width x Weight) (mm)	4000x1350x1550	4650x1500x1650	4650x1500x1650
Total Weight (kg)	2200	2500	2800

Zhengzhou Changli Machinery Manufacturing Co., Ltd.: Contact nameAllen lee; Phone0086-371-66985358; AddressNO.168 Zhengshang Road Shangjie distric Zhengzhou Henan. Zhengzhou,Henan
