Product Details
| Standard or Nonstandard | Standard | Structure | Regulating | |
| Pressure | High Pressure | Power | Other, electirc Rotary Valve | |
| Material | Casting | Temperature of Media | High Temperature | |
| Media | Other, Granular and powder Rotary Valve | Port Size | 200mm Rotary Valve | |
| Place of Origin | Henan, China | Model Number | GY-200*200 Rotary Valve | |
| Brand Name | YU JIE GY-200*200 Rotary Valve |
Product Description
Round and Square Rotary Valve
I. Brief Introduction
Rotary valve, also named vane feeder, composed of shell, rotors, sealing units, reducer and electric motor. When it works, the material falls by gravity from the upper silo and fills the clearance between rotors. As the rotor rotates, the material will unload through the lower gate.
The rotary valve can ensure quantitative and continuous unloading.
We supply round and produce round and square flange rotary valve.
II. Sketch Design
III. Models and Technical Data
Model | Capacity (m3/h) | Rotation Speed (r/min) | Feeding and Discharging Diameter (L*W)mm | Driving Mode | Gear Reducer | Dimension (L*W*H)mm | Weight (kg) | ||
Model | Power (kw) | Rotating Speed (r/min) | |||||||
GY-Φ200*200 | 4 | 20 | 200*200 | Chainwheel | YTC561 | 1.5 | 31 | 570*300*300 | 67 |
7 | 31 | Coupling | |||||||
GY-Φ200*300 | 6 | 20 | 200*300 | Chainwheel | YTC561 | 1.5 | 31 | 670*300*300 | 77 |
10 | 31 | Coupling | |||||||
GY-Φ300*300 | 15 | 20 | 300*300 | Chainwheel | YTC561 | 1.5 | 31 | 760*400*450 | 155 |
23 | 31 | Coupling | |||||||
GY-Φ300*400 | 20 | 20 | 300*400 | Chainwheel | YTC562 | 2 | 31 | 860*400*450 | 174 |
31 | 31 | Coupling | |||||||
GY-Φ400*400 | 35 | 20 | 400*400 | Chainwheel | YTC751 | 3 | 31 | 925*520*600 | 231 |
53 | 31 | Coupling | |||||||
GY-Φ400*500 | 43 | 20 | 400*500 | Chainwheel | YTC751 | 3 | 31 | 1025*520*600 | 268 |
67 | 31 | Coupling | |||||||
GY-Φ500*500 | 68 | 20 | 500*500 | Chainwheel | YTC752 | 5.5 | 31 | 1075*640*760 | 550 |
106 | 31 | Coupling | |||||||
IV. Our Advantages
- With more than 30 years history
- Accept customized order, design and produce according to customer's special requirement
- Audited and professional manufacturer and exporter
- Quality and quantity assured
- Fist-class after sell services
- Competitive prices
- Favorable payment terms
- Prompt supply
V. Key Words
Rotary valve, vane feeder, impeller
