Electric Concrete Mortar Pump Machine 20m3/h
1. Mortar = water + cement + sand (small aggregate)
2. Concrete = Water + cement + sand + stone ( cose aggregate )
3. This concrete motor pump is for conveying small aggregate concrete or backfill layer mortar used in ground floor and ground warmth.
Main Technical Parameters
Item | XHBT-20S Electric Concrete Mortar Pump Machine 20m3/h |
Max. Theoretical Throughput (m3/h) | 20m3/h |
Max. Pumping Pressure (MPa) | 8 |
Max. Theoretical Vertical Conveying Distance (m) | 110 |
Max. Theoretical Horizontal Conveying Distance (m) | 400 |
Max. Aggregate Diameter (mm) | 30 |
Slump (cm) | 12~23 |
Conveying Pipe Radius (mm) | 100A/70A |
Number of Conveying Cylinder (piece) | 2 |
Conveying Cylinder Bore * Piston Stroke (mm) | Φ140*1000 |
Hydraulic Oil Tank Capacity (L) | 240 |
Feeding Height (mm) | 1100 |
Hopper Capacity (m3) | 0.35 |
Power of Main Electric Motor (kw) | 37 |
Dimension (Length*Width *Height) (mm) | 4650*1500*1650 |
Total Weight (kg) | 2800 |
We also supply other models:
1. XHBT-15SA----15m3/h electric concrete mortar pump
2. XHBT-20SD----20m3/h electric concrete mortar pump
3. XHBT-20SR----20m3/h diesel concrete mortar pump
4. HBTS30.10-37E---30m3/h electric concrete mortar pump
5. HBTS30.10-83R ----30m3/h diesel concrete mortar pump
