Product name |
Multi Purpose DistributionFiber Optic Cable GJPFJV |
Introduction |
GJPFJV Multi Purpose Distribution use 6-fiber subunits(900 um tight buffer fiber ,aramid yarn as strength member),A fiber reinforced plastic(FRP) locates in the center of core as a non-metallic strength member,The subunits are stranded around the cable core,The cable is completed with a LSZH(Low smoke,Zero halogen,Flame-retardant)jacket. |
Characteristics |
Stranded non-metallic strength member structure ensure the cable endure larger tensile strength |
Compact structure with high fiber capacity and density | |
All dielectric structure protect it from enectromagnetic influence | |
The jacket anti-corrosion, anti-water, anti-ultraviolet radiation, flame-retardant and harmless to environment etc. | |
Scientific desigh with serious processing art | |
Application |
Indoor any purpose cable distribution |
Backbone distribution cable in a building | |
Standards |
Comply with standard YD/T 1258.2-2003,IECA-596,GR-409,IEC 60794-2-10/11,etc; and meet the requirements of UL approval for OFNR and OFNP. |
Technical Parameter Of GJPFJV
Cable Code |
Cable Diameter mm |
Cable Weight Kg/km |
Tensile Strength Long/Short term N |
Crush Resistance Long/Short term N/100mm |
Bending Radius Dynamic/Static mm |
GJPFJV-024 |
10.4±0.5 |
96 |
400/1320 |
300/1000 |
20D/10D |
GJPFJV-030 |
12.4±0.5 |
149 |
400/1320 |
300/1000 |
20D/10D |
GJPFJV-036 |
13.5±0.5 |
185 |
400/1320 |
300/1000 |
20D/10D |
GJPFJV-048 |
15.7±0.5 |
265 |
400/1320 |
300/1000 |
20D/10D |
GJPFJV-060 |
18.0±0.5 |
350 |
400/1320 |
300/1000 |
20D/10D |
GJPFJV-072 |
20.5±0.5 |
440 |
400/1320 |
300/1000 |
20D/10D |
GJPFJV-096 |
20.5±0.5 |
448 |
400/1320 |
300/1000 |
20D/10D |
GJPFJV-108 |
20.5±0.5 |
448 |
400/1320 |
300/1000 |
20D/10D |
Note:
1. Cables can be supplied with a range of single mode or multimode fibers.
2. Specially designed Cable structure is available on request.
Chengdu Datang Communication Cable, Co. Ltd. has built up optical cable and electrical
cable factory with all kinds of advanced equipments. The main part includes an 8000-sq.m
optical cable’s workshop, a 7600-sq.m Physical-foaming coaxial cable workshop and a 6200-
sq.m digital cable’s workshop. Its annual production is as follows: 3.5 million Pairs kilometers
of optical cable,70,000 kilometers of coaxial cable, and 800,000 boxes of digital cable.
