2012 GD6/8-200Y Automatic Liquid Product Filling Machine

Specifications

1:Reduce labour resources (1-2 person)
2: Easy operation
3:Safty and hygiene
4:High precision
5:Frequency control



Main technical parameters







Model	GD6/8-200Y
Bag type	Heat-seal
Bag sizes	W:80-200mm L:100-300mm
Filling range	≤ 1000g
Packing speed	15-68 bags/ min( depending on the product and filling weight)
Package accuracy	Error ≤± 1%
Compressed air	0.6 m3/min(supply by user)
Overall dimensions	2250*1500*1500mm







Applications:



1. Solid: candy, chocolate, rock candy, cookies, cakes, peanuts, green beans, pistachios, nuts, cooked foods, pickles, puffed food, dailynecessities, etc.
2. Granule: MSG, chicken, sugar, melon seeds, nuts,capsules, granular medicines, seeds, feed, pesticides, fertilizers, chemical raw materials.
3. Powder: spices, monosodium glutamate, salt, glucose, refined sugar, milk powder, detergent powder, pesticides, fertilizers, chemical raw materials, etc
4. Liquid: rice wine, soy sauce, rice vinegar, fruit juice, beverage, detergent, etc.
5. Thick liquid: tomato sauce, peanut butter, jam, chili sauce, bean paste, etc.
6. Other materials can be bagged
