GCr15 52100 Bearing Steel Bar
- 1000 Ton / Tons per Month
- Qingdao Port China
- T/T
You May Like
Product Details
| Steel Grade | Alloy Steel | Standard | AISI, ASTM, BS, DIN, GB, JIS | |
| Dimensions | 18-60MM | Place of Origin | Shandong, China | |
| Brand Name | ZY | Model Number | Alloy steel bar | |
| Technique | Hot Rolled | Alloy Or Not | Is Alloy | |
| Type | Carbon Steel Bar |
Product Description
GCr15 / AISI 52100 Bearing Steel Bar
1) The comparison table for each standard:
| GB | ISO | ASTM | JIS | DIN | NF | Sweden |
| GB/T18254 | 9001:2008 | 52100 | SUJ2 | 100Cr6 | 100C6 | SKF3 |
2) Chemical compositon:
Steel No. | Symbol | Chemical Compostion(Wt%) | |||||
| Gcr15 | AISI52100 | C 0.95-1.05 | Cr 1.30-1.65 | Si 0.15-0.35 | Mn 0.25-0.45 | P <0.027 | S <0.025 |
3) Thermal properties
| Thermal Properties | Conditions | ||
| T (0C) | Treatment | ||
| Thermal Expansion (10-6/0C) | 11.9 | 0-100 | Annealed |
4) Temper Diagram
5) Delivery State
Rough grinding surface, sheared, sawn with abrasive disc cutter and chamfered end
6) Application:
- Bearing and rolling elements
- Machinery
- Mould
- Stamping
- Combustion Motor
- Electric Motor Car
- Computer Numerical Control
- Rolling Mill
- Drilling Rig
- General Machinery
- Measuring Tool
- Bearing Ball & Bearing Outer Ring
