Prefabricated house, China supplier prefab homes with bathroom accessories
Prefabricated homes (ZA type) is flexible modular house. The size and layout can be designed as customers’requirements and local climate. When delivery, it is knock-down to save space. Based on bolts connection without welding work, the prefabricated houses could be assembled and disassembled easily and six common workers can finish 50m2 in 8 hours according to instruction and CD.
The detailed information as follows:
No. | Sort | Name | Specification |
1 | Specification | length | No limited |
2 | Width | Less than 12m | |
3 | Wall height | 3000mm | |
4 | Clear height | 2600mm | |
5 | Roof slope | 1:5 | |
6 | Standard accessory | Wall board | 75mm or 100mm thickness sandwich panel, 0.35mm steel sheet, 13kg/m3 polystyrene density. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.546w/.k. |
7 | Roof board | 75mm thickness sandwich panel, 0.35mm steel sheet, 13kg/m3 polystyrene density. Heat Insulated coefficient is 0.041w/m.k. Heat transfer coefficient is 0.546w/.k. | |
8 | Outside door | Security door, single door with dimensions of 900*2100mm, furnished with a handle lock with 3keys. Doorframe is made of 1.2mm steel, and door is made of 0.7 mm steel, 90mm thick rock wool insulation foam. | |
| Inside door | SIP, single door with dimensions of 750*2000mm, furnished with a cylinder lock with 3keys. Doorframe is made of aluminum, 50mm thick EPS insulation foam. | |
9 | Window(W-1) | PVC, white color, with dimensions of 1200*1200mm, glazed with glass in a thickness of 5mm, two bay fixed, and two bay sliding, supplied with fly screen. | |
| Window(W-2) | PVC, white color, with dimensions 500*500mm, glazed with glass in a thickness of 5mm, casement opening, supplied with fly screen. | |
10 | Channel | Galvanized Steel Plain Sheet press moulding Material: Painted steel | |
11 | Post | Square steel tube, Material: Galvanized steel | |
12 | Purline | C style steel Material: Galvanized steel | |
13 | Roof truss | Gabled truss, Material: Galvanized steel Q235 | |
| Decoration and connection | Color steel sheet, 0.35mm thick | |
| Elevated ceiling | Ceiling of mineral wool acoustic panel in room and aluminium panel in bathroom and kitchen | |
20 | Option | Decorative floor | PVC, laminated or ceramic tile |
21 | Drainage system | Provided plan, design and construction | |
22 | Electric system | Provided plan, design and construction | |
25 | Technical parameter | Bearing load | 50kg/m2, can be adjusted according to climate |
27 | Wind pressure: | 0.5KN/M2, can be adjusted according to climate | |
28 | Fire proof | B2 grade | |
29 | Resistant temperature | -25 to 50 | |
30 | The resistant earthquake grade | 7 fission activate. |
