Place of Origin Hebei, China
Brand Name LQ
Model Number U head Jack Scaffolding Set



 U head Jack Scaffolding Set



U head Jack Scaffolding Set SPECIFICATIONS

1)Solid bar

a) length:300,400mm,600m,800m etc.

b) O.D.:28mm,30mm,32mm,34mm,38mm

2)Hollow tube:

a) length:300,400mm,600m,800m etc.

b)O.D.:36mm,38mm,40mm,48mm



Both the solid bar or hollow tube jack base can be with or without U-Head



3) surface: Powerder coating, white galvanized or Black finish





 U head Jack Scaffolding Set -Adjustable Base Jack



Pipe  Plate
M30(Solid) x 600mm 120mm x 120mm x 4mm
M32(Solid) x 600mm 140mm x 140mm x 4mm
M34(Solid) x 600mm 150mm x 150mm x 6mm
38(Hollow) x 4 x 600mm 120mm x 120mm x 5mm





U head Jack Scaffolding Set -Adjustable Up U-Head Jack





Pipe U-Head
M30(Solid) x 600mm 120mm x 100mm x 45mm x 4mm
M32(Solid) x 600mm 150mm x 120mm x 50mm x 4.5mm
M34(Solid) x 600mm 150mm x 150mm x 50mm x 6mm
38(Hollow) x 4 x 600mm 120mm x 120mm x 30mm x 3mm







U head Jack Scaffolding Set -Nut



Nut Weight
Nut Type A 0.2KG
Nut Type B 0.25KG
Nut Type C 0.3KG
Nut Type D 0.4KG






U head Jack Scaffolding Set -Hollow



Leading screw

U shape plate

Jack nut

Total weight

34×4×400mm

150×120×50×5mm

0.55kg

2.91kg

34×4×600mm

150×120×50×5mm

0.55kg

3.739kg

38×4×400mm

150×150×50×6mm

0.50kg

3.607kg

38×4×600mm

150×150×50×6mm

0.50kg

4.278kg

38×4×780mm

150×150×50×6mm

0.50kg

4.881kg

48×4/5×600mm

150×150×50×8mm

1.0kg

6.241/6.818kg

48×4/5×820mm

150×150×50×8mm

1.0kg

7.195/7.984kg



 quick adjustment scaffolding jack -Solid



Leading screw

U shape plate

Jack nut

Total weight

30×600mm

150×120×50×4/5mm

0.25kg

4.092/4.327kg

32×600mm

150×120×50×4/5mm

0.30kg

4.572/4.807kg

34×600mm

150×120×50×4/5mm

0.40kg

5.132/5.367kg

30×400mm

150×120×50×4/5mm

0.25kg

3.126/3.361kg

32×400mm

150×120×50×4/5mm

0.30kg

3.463/3.698kg

34×400mm

150×120×50×4/5mm

0.40kg

3.869/4.104kg



U head Jack Scaffolding Set  SHOW



U head Jack Scaffolding Set/ Formwork Prop/Adjustable Shoring Props

U head Jack Scaffolding Set/ Formwork Prop/Adjustable Shoring Props

Company Information

U head Jack Scaffolding Set/ Formwork Prop/Adjustable Shoring Props



Adjustable u head jack base with nut PRODUCTS  PROCESS
